凯斯零件查询(BTX11) - CASE IH BALE THROWER (1/02-) (70.280.15[2]) - HYDRAULIC CYLINDER, DIRECTION CONTROL, P.I.N. HBJ0003526 & AFTER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
462 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87019621
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 28.57mm Rod, 152.4mm Stroke
|
PA
Superseded by part number: 87019620
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Cylinder Barrel
|
| 3. |
280724
|
[1] |
LOCK NUT,3/4" - 16
|
NH
|
| 4. |
87025721
|
[1] |
PISTON
|
PA
Piston Superseded by part number: 47583103
|
| 5. |
86553483
|
[1] |
SEAL
|
NH
3 Piece, Piston
|
| 6. |
87026043
|
[1] |
PISTON ROD
|
PA
Rod, Piston
|
| 7. |
87025433
|
[1] |
HEAD
|
PA
Head, Cylinder
|
| 8. |
238-6224
|
[1] |
O-RING,0.139" Thk x 1.734" ID, -224, Cl 6, 90 Duro
|
CAS
Superseded by part number: 235782
|
| 9. |
270103
|
[1] |
BACK-UP RING,45.01mm ID x 51mm OD x 1.27mm Thk
|
NH
Backup, 1.772" ID x .043" Thk
|
| 10. |
235758
|
[1] |
O-RING,1.115" ID x 1.387" OD x 0.143"
|
NH
1.109" ID x .139" Thick
|
| 11. |
134371
|
[1] |
SEALING WASHER
|
NH
SEALRING Backup, 1.141" ID x .040" Thick
|
| 12. |
128406
|
[1] |
SEAL,28.57mm ID x 41.45mm OD x 6.35mm Thk
|
NH
Rod Wiper
|
| 13. |
87025442
|
[1] |
SEAL KIT
|
PA
Seals
|
| 14. |
705914
|
[1] |
ORIFICE
|
NH
.040"
|
