纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (9.651[02]) - ROPS CANOPY - OPTIONAL CODE 76029305 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
918 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79106018 | [1] | PANEL | LEC |
| 2. | 79103754 | [1] | BEZEL | LEC |
| 3. | 12648131 | [6] | WASHER,6.15mm ID x 15mm OD x 4mm Thk | LEC |
| 4. | 13276017 | [6] | SCREW,Pozidriv Pan Hd, M6 x 12mm, Cl 5.8, Full Thd | JES |
| 5. | 79100779 | [1] | SUPPORT | LEC |
| 6. | 14496531 | [2] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 7. | 16043231 | [2] | SCREW,Hex, M8 x 16mm, Cl 10.9, Full Thd | LEC |
| 8. | 76008003 | [1] | REAR VIEW MIRROR | LEC |
