凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (008) - UNIVERSAL DRIVE SHAFT, ANGLE DRIVE - INTERMEDIATE DRIVE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
399 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8306261
|
[1] |
DRIVE SHAFT
|
R
assy.
|
| 2. |
8173062
|
[1] |
DRIVE SHAFT
|
R
half 6-Teil. Anschluss
|
| 3. |
8175801
|
[1] |
SHIFTER FORK
|
R
Extension forke
|
| 4. |
933110R1
|
[4] |
SNAP RING,M32, Int
|
IH
Circlip 32x1,2 Superseded by part number: 301646
|
| 5. |
9416510
|
[1] |
CROSS
|
R
Centre cross ass.
|
| . . |
2449460
|
[1] |
NIPPLE, LUBE
|
R
Grease nipple Bm 8x1
|
| 6. |
9416560
|
[1] |
FORK TEDDER
|
R
Fork
|
| 7. |
838-51080
|
[1] |
LOCK PIN,M10 x 80 Slotted
|
CAS
Tensioning pin 10 x 80 Superseded by part number: 440437
|
| 8. |
9403420
|
[1] |
DRIVE SHAFT
|
R
Profile tube 680 lang, 680 lang
|
| 10. |
8173072
|
[1] |
DRIVE SHAFT
|
R
half 21-Teil. Anschluss
|
| 11. |
8130331
|
[1] |
DRIVE SHAFT
|
R
Profile tube 2A-665, 685 lang
|
| 13. |
9416600
|
[1] |
FORK TEDDER
|
R
Fork
|
| 16. |
8173092
|
[1] |
SHIFTER FORK
|
R
Extension forke
|
| 17. |
2334430
|
[2] |
SCREW
|
R
Hexagonal screw M14x1,5 x 70
|
| 18. |
2390040
|
[2] |
NUT
|
R
Securing nut Vm14x1,5
|
| 19. |
8177860
|
[1] |
NIPPLE, LUBE
|
R
Grease nipple, Start Serial: 04400305 Superseded by part number: 817786N0
|
