凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (007[A]) - ANGLE DRIVE Case Agriculture

广数供应链运营团队, 15 02月, 2025，浏览： 177 次

Pos.	Part No	Qty	Parts name	Comments
1.	8300321	[1]	GEARBOX ASSY	R Angle drive
2.	2157930	[2]	GUIDE	R Shaft seal ring As 65x 90x10 Superseded by part number: NLS
3.	R2159350	[12]	SCREW	R Socket head screw
4.	8306670	[1]	HOUSING	R
5.	2159300	[1]	SHIM	R 1,0 mm
5.	2344290	[1]	SHIM	R 0,5 mm
5.	2344180	[1]	SHIM	R 0,3 mm
5.	2330380	[1]	SHIM	R 0,1 mm
6.	2157910	[1]	BEARING	R Ta.roller bearing 320 17x
7.	8307670	[1]	SET OF DOWELS	R Bevel gear set
8.	8306650	[1]	HOUSING	R
9.	8173040	[1]	VALVE	R Breather valve
10.	2381470	[2]	GASKET	R Seal ring
11.	2443520	[1]	PLUG	R Locking screw
12.	2157880	[1]	OIL SEAL	R Shaft seal ring A 70x 90x10
13.	8306740	[1]	NUT	R Shaft nut
14.	933077R1	[1]	SNAP RING,M90, Int	IH Circlip 90x3 Superseded by part number: 370013
15.	2359890	[1]	BEARING	R Ta.roller bearing 302 10
16.	2157920	[1]	OIL SEAL	R Shaft seal ring A 50x 80x10
17.	614-12040	[8]	BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd	IH Superseded by part number: 86629541
18.	2351340	[8]	WASHER	R Spring washer A12
19.	8306660	[1]	SHIN	R Flange
20.	8307660	[1]	SHIM	R 1,0 mm
20.	8306750	[1]	SHIM	R 0,4 mm
20.	8306770	[1]	SPACER	R Shim 0,3 mm
20.	8306760	[1]	SHIM	R 0,1 mm
21.	2123850	[1]	GASKET	R O-ring 128 x3 -N
22.	2380740	[1]	BEARING	R Ta.roller bearing 322 10
23.	2392430	[1]	PLUG	R Locking screw M18x1,5
24.	2119180	[1]	BEARING	R Ta.roller bearing 320 13x
25.	2159310	[1]	SHIM	R 1,0 mm
25.	2157981	[1]	SHIM	R 0,5 mm
25.	2126871	[1]	SHIM	R 0,3 mm
25.	2126861	[1]	SHIM	R 0,1 mm
26.	8306680	[1]	HOUSING	R cover
