纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (9.654[01]) - SWEEPS - ROPS CANOPY - OPTIONAL CODE 79093160 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
351 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79086224 | [1] | GUARD | LEC- FRONT |
| 2. | 79109793 | [2] | SUPPORT | LEC- ASSY Superseded by part number: 76067987 |
| 3. | 79060730 | [2] | BUSHING | LEC |
| 4. | 79086337 | [1] | GRILLE | LEC |
| 5. | 79085442 | [4] | SCREW,M24 x 2 x 2mm | LEC |
| 6. | 76001715 | [6] | BRACKET | LEC |
| 7. | 12575321 | [4] | NUT,M24 x 2, Cl 10 | LEC |
| 8. | 11408631 | [6] | BOLT,Hex, M20 x 1.5 x 45, 10.9, Full Thd | LEC Superseded by part number: 514-1211 |
| 9. | 79032222 | [6] | WASHER,21mm ID x 40mm OD x 8mm Thk | LEC |
| 10. | 11107331 | [12] | SCREW,Hex, M10 x 55mm, Cl 10.9 | LEC |
| 11. | 14496631 | [12] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 12. | 10615779 | [12] | LOCK WASHER,Ext Tooth, M10 | MKT Superseded by part number: 12605671 |
| 13. | 15835231 | [4] | BOLT,Hex, M16 x 1.5 x 70mm, Cl 10.9 | BHB |
| 14. | 79005240 | [8] | WASHER,16.8mm ID x 36mm OD x 8mm Thk | LEC |
| 15. | 79093067 | [1] | SUPPORT | LEC- ASSY REAR LEFT |
| 16. | 79093069 | [1] | SUPPORT | LEC- ASSY REAR RIGHT |
| 17. | 15981831 | [4] | BOLT,Hex, M16 x 1.5 x 120mm, Cl 10.9 | MKT Superseded by part number: 15981830 |
