| 1. |
8178391
|
[1] |
PINION
|
R
Sprocket 15 Z. 19,05 Tlg
|
| 2. |
2331770
|
[1] |
WASHER
|
R
11 x 40 x4 Superseded by part number: 84814141
|
| 3. |
98-029441
|
[1] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 4. |
814-10020
|
[1] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43138
|
| 5. |
8304391
|
[1] |
CHAIN (AG)
|
R
Roller chain 19,05 T 114Ro
|
| 6. |
9321511
|
[1] |
LINK
|
R
Chain lock str. 19,05x11,68
|
| 7. |
2335680
|
[1] |
LINK
|
R
Chain lock bend. 19,05x11,68
|
| . . |
2334890
|
[1] |
LINK
|
R
Twin link 19,05x11,68
|
| 8. |
9321530
|
[1] |
CHAIN LINK
|
R
Chain inner link 19,05x11,68
|
| 9. |
2375902
|
[3] |
WASHER
|
R
31
|
| 10. |
9641111
|
[2] |
COVER ASSY
|
R
Washer
|
| 11. |
9641101
|
[1] |
HOOK
|
R
Pawl
|
| 12. |
9254520
|
[1] |
SPRING
|
R
Compress.spring
|
| 13. |
8160011
|
[1] |
LARGE PLATE
|
R
Hub
|
| 14. |
9641092
|
[1] |
PINION
|
R
Sprocket Z=34 ;3/4"
|
| 15. |
2369420
|
[2] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1 Superseded by part number: 321204
|
| 16. |
814-8035
|
[3] |
BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8
|
CAS
Superseded by part number: 412479
|
| . . |
43362
|
[3] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[3] |
WASHER
|
FO
Contact washer A8 Superseded by part number: 322358
|
| 17. |
0076150
|
[1] |
KEY
|
R
Gib-head key 10x 8x 50
|
| 20. |
7510260
|
[1] |
ROD
|
R
Eye bolt
|
| 21. |
9086870
|
[1] |
SPRING
|
R
Tension spring
|
| 22. |
2338000
|
[1] |
WASHER
|
R
Back-up washer S 22x 32
|
| 23. |
0085250
|
[2] |
SPACER
|
R
Bushing
|
| 24. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 25. |
8161650
|
[1] |
LEVER
|
R
|
| 26. |
2351810
|
[2] |
CLIP
|
R
Circlip 47x1,75 Superseded by part number: 300647
|
| 27. |
8187670
|
[1] |
GEAR WHEEL
|
R
Tension pinion 14Zx19,05x11,68
|
| 28. |
537290R91
|
[1] |
BALL BEARING,20mm ID x 47mm OD x 14mm W
|
IH
Grvd.ball bearing 6204-2RS Superseded by part number: 84330054
|
| 29. |
933123R1
|
[1] |
SNAP RING,M20, Ext
|
IH
Circlip 20x1,2 Superseded by part number: 370024
|
| 30. |
2369440
|
[1] |
LUBE NIPPLE
|
R
Grease nipple CS 6x1
|
| 31. |
2368280
|
[1] |
WASHER
|
R
|
| 33. |
931171R1
|
[1] |
BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd
|
IH
Hexagonal screw M 8x 16 Superseded by part number: 16043224
|
| 34. |
6852110
|
[1] |
SUPPORT
|
R
|
| 35. |
614-8020
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| 36. |
6864010
|
[1] |
ANGLE
|
R
|
