凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (012) - PICK-UP DRIVE, R.H. Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
324 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8178391
|
[1] |
PINION
|
R
Sprocket 15 Z. 19,05 Tlg
|
| 2. |
2331770
|
[1] |
WASHER
|
R
11 x 40 x4 Superseded by part number: 84814141
|
| 3. |
98-029441
|
[1] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 4. |
814-10020
|
[1] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43138
|
| 5. |
8241391
|
[1] |
TENSIONER
|
R
Tensioning block
|
| 6. |
2364620
|
[1] |
SCREW
|
R
Flat head bolt M10x 60
|
| . . |
2383160
|
[1] |
NUT
|
R
Securing nut Vm10
|
| . . |
2393941
|
[1] |
WASHER
|
R
Contact washer B10
|
| 7. |
2332931
|
[1] |
CHAIN (AG)
|
R
Roller chain 19,05 T 73Ce
|
| 8. |
9321530
|
[1] |
CHAIN LINK
|
R
Chain inner link 19,05x11,68
|
| 9. |
2335680
|
[1] |
LINK
|
R
Chain lock bend. 19,05x11,68
|
| . . |
2334890
|
[1] |
LINK
|
R
Twin link 19,05x11,68
|
| 10. |
9321511
|
[1] |
LINK
|
R
Chain lock str. 19,05x11,68
|
| 11. |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
Spacer ring
|
| 12. |
8192600
|
[1] |
DRIVE SPROCKET
|
R
Sprocket 19,05 Tg 35Z
|
| 13. |
2447980
|
[1] |
KEY
|
R
Gib-head key 8x 7x 45
|
