纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (9.665[02]) - AIR CONDITIONING - OPTIONAL CODE 76042216 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
440 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76040469 | [1] | FLEXIBLE HOSE,18.00 mm ID x 2150.00 mm | LEC Superseded by part number: 78100219 |
| 2. | 76040468 | [1] | HOSE,18.00 mm ID x 2400.00 mm | LEC Superseded by part number: 76014938 |
| 3. | 10182611 | [2] | BANJO BOLT,M20 x 1.5 x 36mm | MOD Superseded by part number: 10182617 |
| 4. | 79083842 | [4] | HOSE CLAMP,M16-27 | LEC Superseded by part number: 18088392 |
| 5. | 76041521 | [1] | RIGID TUBE,15 mm ID, 18 mm OD, 130, 80 mm Length | LEC |
| 6. | 98474312 | [2] | SEAL | TOR |
| 7. | 10450890 | [1] | RETAINER COLLAR | COE Superseded by part number: |
| 8. | 76028403 | [1] | HYD CONNECTOR | LEC |
| 9. | 79083843 | [3] | HOSE CLAMP,M20-35 | LEC Superseded by part number: 13000690 |
| 10. | 10450990 | [2] | CLAMP,26mm, Coat, 9mm Bolt Hole, P Type | LEC26 Superseded by part number: 86637977 |
| 11. | 16043331 | [1] | SCREW,Hex, M8 x 1.25 x 18mm, Cl 10.9, Full Thd | LEC |
| 12. | 14496531 | [1] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 13. | 16100821 | [1] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
