纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (9.665[01]) - AIR CONDITIONING - HEATER - OPTIONAL CODE 76042216 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
831 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79113684 | [1] | METAL LINER | LEC- FRONT |
| 2. | 79113430 | [1] | METAL LINER | LEC- LOWER |
| 3. | 79113427 | [1] | METAL LINER | LEC- UPPER |
| 4. | 76035686 | [1] | AIR CONDITIONER | LECAIR CONDITIONING - ASSY SEE TAV.6 Superseded by part number: 76093962 |
| 5. | 79107307 | [1] | LEVER | LEC |
| 6. | 79092755 | [1] | DECAL | LEC |
| 7. | 79079424 | [1] | CLIMATE CONTROL SWITCH | LEC |
| 8. | 79089651 | [1] | KNOB | LEC |
| 9. | 79106521 | [2] | PIN | LEC |
| 10. | 12575421 | [2] | NUT | LEC |
| 11. | 14496431 | [2] | WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk | LEC Superseded by part number: 86588450 |
| 12. | 79106520 | [1] | BRACKET | LEC |
| 13. | 79107221 | [1] | CABLE | LEC |
| 14. | 79092152 | [1] | SWITCH | LEC |
| 15. | 79092153 | [1] | DECAL | LEC |
| 16. | 16040731 | [4] | BOLT,Hex, M8 x 1.25 x 50mm, Cl 10.9, Full Thd | LEC8X50 Superseded by part number: 87015731 |
| 17. | 16104121 | [4] | NUT,M8 x 1.25, Cl 10 | LEC Superseded by part number: 17152821 |
| 18. | 79089658 | [8] | PAD | BHB |
| 19. | 14496531 | [8] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 20. | 12645031 | [4] | WASHER,8.45mm ID x 21mm OD x 3mm Thk | LEC |
| 21. | 10403580 | [1] | RING | MKT10X1,5 |
| 22. | 79113744 | [1] | METAL LINER | LEC- RIGHT |
| 23. | 10902031 | [26] | BOLT,Hex, M6 x 12mm, Cl 10.9 | LEC Superseded by part number: 86508616 |
| 24. | 79097703 | [26] | WASHER | LEC |
| 25. | 79107306 | [2] | BLOCK | LEC |
| 26. | 10445831 | [2] | BOLT,Hex, M4 x 8mm, Cl 10.9, Full Thd | LEC8X4 |
| 27. | 15645501 | [2] | SELF-TAP SCREW,Cross Pan Hd, M4.8 x 16mm | LEC Superseded by part number: 15645570 |
| 28. | 79106519 | [4] | NUT | LEC |
