凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (059) - TWO-LINE AIR BRAKE (VAR.9046) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
528 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
2155090
|
[1] |
UNION
|
R
Connection
|
| 2. |
2357860
|
[2] |
OIL SEAL
|
R
Seal ring
|
| 3. |
8161310
|
[1] |
CYLINDER, GAS
|
R
Diaphragm cylind.
|
| 4. |
2393910
|
[2] |
WASHER
|
R
Contact washer A16
|
| 5. |
2375190
|
[2] |
NUT
|
R
Hexagonal nut M16x1,5
|
| 7. |
2116490
|
[2] |
COLLAR CLAMP
|
R
Hose clamp
|
| 8. |
2155070
|
[1] |
UNION
|
R
Hose support
|
| 9. |
8161330
|
[1] |
GASKET
|
R
Brake hose
|
| 10. |
2116400
|
[1] |
UNION
|
R
Hose support
|
| 11. |
2116460
|
[2] |
GASKET
|
R
Seal ring
|
| 12. |
2116450
|
[2] |
SPACER
|
R
Pressure ring
|
| 13. |
6722090
|
[5] |
CLAMP
|
R
Attaching clamp
|
| 14. |
6071100
|
[5] |
SHIN
|
R
Rubber bearing
|
| 15. |
8304760
|
[1] |
PIPE
|
R
Hydr. pipe
|
| 16. |
2116440
|
[1] |
NUT
|
R
Overthrow nut
|
| 17. |
6335901
|
[1] |
OLIVE
|
R
Nipple
|
