凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (063) - HYDRAULIC BRAKE SYSTEM (VAR.9047) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
985 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
2154810
|
[1] |
OLIVE
|
R
Nipple P-R10L/S
|
| 2. |
2154820
|
[1] |
NUT
|
R
Overthrow nut A3 L10
|
| 3. |
8304820
|
[1] |
PIPE
|
R
Hydr. pipe
|
| 4. |
6836580
|
[2] |
SHIN
|
R
Rubber bearing
|
| 5. |
6832540
|
[2] |
COLLAR CLAMP
|
R
Attaching clamp
|
| 6. |
2387070
|
[1] |
SLEEVE CYLINDER
|
R
Connect.union L10
|
| 7. |
2114360
|
[2] |
PARTS SALES BULLETIN
|
R
O-ring 7,5 x1,5 Superseded by part number: R2114360
|
| 8. |
6836590
|
[1] |
CYLINDER END CAP
|
R
Rubber bearing
|
| 9. |
6722090
|
[1] |
CLAMP
|
R
Attaching clamp
|
| 10. |
6895480
|
[1] |
HOSE
|
R
pipe
|
| 11. |
8170820
|
[1] |
UNION
|
R
Clutch sleeve Bg 1 Ra=10
|
| 12. |
8171650
|
[1] |
UNION
|
R
Screw-in union Bg 1
|
| 13. |
2332250
|
[1] |
GASKET
|
R
O-ring 18 x2 -N
|
