凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (064) - HYDRAULIC BRAKE SYSTEM (VAR.9047) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
716 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
814-16035
|
[2] |
BOLT,Hex, M16 x 2 x 35mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86529976
|
| . . |
190003871339
|
[2] |
NUT
|
S
Hex, M16 Superseded by part number: 392530
|
| . . |
2393910
|
[2] |
WASHER
|
R
Contact washer A16
|
| 2. |
8169020
|
[1] |
STAY
|
R
Attaching bracket
|
| 3. |
2114360
|
[1] |
PARTS SALES BULLETIN
|
R
O-ring 7,5 x 1,5 Superseded by part number: R2114360
|
| 4. |
2386930
|
[1] |
UNION
|
R
Angle union L10 Superseded by part number: 190003551459
|
| 5. |
9042621
|
[1] |
PIN
|
R
|
| 6. |
2363810
|
[2] |
WASHER
|
R
28 x 16 x3
|
| 7. |
732-5032
|
[2] |
COTTER PIN,M5 x 32
|
CAS
Split pin 5 x 28
|
| 8. |
6834531
|
[1] |
HOSE
|
R
pipe
|
| 9. |
8304840
|
[1] |
PIPE
|
R
Hydr. pipe
|
| 10. |
8169950
|
[1] |
CYLINDER ASSY.
|
R
Hydr. cylinder siehe Bildtafel 65
|
| 11. |
8169030
|
[1] |
ROD
|
R
Guide bolt
|
| 12. |
2375190
|
[2] |
NUT
|
R
Hexagonal nut M16x1,5
|
| 13. |
6832540
|
[6] |
COLLAR CLAMP
|
R
Attaching clamp
|
| 14. |
6836580
|
[6] |
SHIN
|
R
Rubber bearing
|
| 15. |
2154820
|
[1] |
NUT
|
R
Overthrow nut A3 L10
|
| 16. |
2154810
|
[1] |
OLIVE
|
R
Nipple P-R10L/S
|
| 17. |
2387070
|
[1] |
SLEEVE CYLINDER
|
R
Connect.union L10
|
