纽荷兰零件查询(FD20) - CRAWLER DOZER (L1.01[002]) - HOOD SIDE PLATES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
892 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76001841 | [1] | COWLING | LECHOOD |
| 2. | 73154261 | [1] | SIDE PANEL | NHCOVER, LEFT |
| 2. | 73154262 | [1] | SIDE PANEL | NHCOVER, RIGHT |
| 3. | 11112431 | [20] | SCREW,Hex, M12 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 87015736 |
| 3. | 70911414 | [20] | WASHER | CMI |
| 4. | 79007433 | [1] | SIDE PANEL | LECPLATE, RIGHT |
| 4. | 79007435 | [1] | SIDE PANEL | LECPLATE, LEFT |
| 5. | 73154275 | [2] | DOOR | NH |
| 6. | 73154273 | [1] | CONTROL | NHDOOR, LEFT |
| 6. | 73154274 | [1] | CONTROL | NHDOOR, RIGHT |
| 7. | 73154217 | [4] | RETAINER | NH |
| 8. | 10517071 | [8] | LOCK WASHER,12.2mm ID x 21.1mm OD x 3.1mm Thk | HFILOCKWASHER Superseded by part number: 10517073 |
| 8. | 12646921 | [8] | WASHER,12.2mm ID x 28mm OD x 3mm Thk | BHB Superseded by part number: 16887624 |
| 9. | 73154263 | [1] | SIDE PANEL | NHCOVER, LEFT |
| 9. | 73154264 | [1] | SIDE PANEL | NHCOVER, RIGHT |
| 10. | 73154267 | [1] | SIDE PANEL | NHCOVER, LEFT |
| 10. | 73154268 | [1] | SIDE PANEL | NHCOVER, RIGHT |
| 11. | 73154265 | [1] | SIDE PANEL | NHCOVER, LEFT |
| 11. | 73154266 | [1] | SIDE PANEL | NHCOVER, RIGHT |
| 12. | 11106431 | [4] | SCREW,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LECCAPSCREW Superseded by part number: 9515003 |
| 12. | 12638621 | [4] | WASHER,M10 x 18 x 2 | BHB Superseded by part number: 17095014 |
| 13. | 10902131 | [2] | SCREW,Hex, M6 x 14mm, Cl 10.9, Full Thd | LECBOLT, Hex, M6 x 14, 10.9, Full Thd |
| 13. | 12639701 | [4] | WASHER,6.15mm ID x 11mm OD x 1mm Thk | BHB Superseded by part number: 17094724 |
| 13. | 15896221 | [2] | NUT,Hex, M6, 5.20mm High, Cl 10 | ZED Superseded by part number: 86500688 |
| 14. | 70929160 | [4] | COLLAR | CMICLIP |
| 15. | 70929353 | [4] | GROMMET | CMI |
