纽荷兰零件查询(FD20) - CRAWLER DOZER (L1.01[004]) - HOOD ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
196 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 567406. | 5112606 | [4] | COTTER PIN | TTFSPLIT PIN |
| 8287762. | 8287762 | [2] | BLOCK | LECFASTENING BLOK |
| 10517077. | 10517077 | [1] | LOCK WASHER | MODLOCKWASHER Superseded by part number: 10517071 |
| 15540931. | 15540931 | [1] | BOLT,Hex, M12 x 1.25 x 55mm, Cl 10.9 | TTFBOLT, Hex, M12 x 1.25 x 55, 10.9 |
| 76001494. | 76001494 | [4] | HINGE | LEC |
| 76001495. | 76001495 | [4] | PIN | LECSECURING PIN |
| 76001498. | 76001498 | [4] | WASHER | LEC |
| 76001980. | 76001980 | [1] | GUARD | LECPROTECTION |
| 76010687. | 76010687 | [1] | GUARD | LECPROTECTION |
| 76010885. | 76010885 | [4] | HINGE | NH |
