凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (075[A]) - LIGHTING, REAR, FROM SERIAL NO. 04400025 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
615 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8306350
|
[1] |
STOP
|
R
Tail light holder -
|
| 2. |
9689980
|
[2] |
LIGHT
|
R
Flasher taillight
|
| 3. |
6714400
|
[2] |
BULB
|
R
Reflector red
|
| 4. |
6584030
|
[2] |
LIGHT
|
R
Licenc.plate lamp -
|
| 5. |
1779060
|
[2] |
AUXILIARY ENGINE
|
R
Soffit L 12v 5 w
|
| 6. |
614-8020
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| . . |
43362
|
[4] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[4] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 7. |
0117410
|
[1] |
HARNESS
|
R
Wiring loom, Start Serial: 04400495
|
| 7. |
0116840
|
[1] |
HARNESS
|
R
Wiring loom Bel. quadrant, Serial Range: -04400494
|
| 8. |
2154030
|
[6] |
CLAMP
|
R
Pipe clamp
|
| 9. |
2007060
|
[1] |
SHROUD
|
R
Edge protector 2 X 170 lang
|
| 10. |
2154050
|
[8] |
MOUNTING CLIP
|
R
Pipe clamp
|
| 11. |
2335460
|
[4] |
BULL BLADE
|
R
Lamp Rl 12v21 w
|
| 12. |
2449820
|
[2] |
BULB
|
R
Lamp G 12v10 w
|
| 13. |
2112890
|
[4] |
REFLECTOR
|
R
Rear reflector
|
| 14. |
2379501
|
[4] |
RIVET
|
R
A 4,8x12
|
| 15. |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
Rear reflector
|
| 16. |
8305790
|
[2] |
SUPPORT
|
R
|
| 17. |
614-6020
|
[4] |
BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120100
|
| . . |
825-1406
|
[4] |
NUT,M6, Cl 8
|
CAS
Superseded by part number: 86500688
|
| . . |
2393860
|
[8] |
WASHER
|
R
Contact washer A 6 Superseded by part number: 86588450
|
| 18. |
2420440
|
[4] |
SCREW,Skt Hd, M5 x 16mm
|
R
Socket head screw M 5x16
|
| . . |
2372160
|
[4] |
NUT
|
R
Hexagonal nut M 5
|
| . . |
2150310
|
[4] |
WASHER
|
R
Serrated l.washer A 5,3
|
