凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (076) - ELECTRIC TWINE MONITORING (VAR.9208) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
862 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
2335460
|
[1] |
BULL BLADE
|
R
Lamp Rl 12v21 w
|
| 2. |
09691141
|
[1] |
LIGHT
|
R
Indicator light
|
| 3. |
2339000
|
[1] |
FUSE
|
R
, Start Serial: 04400305
|
| 3. |
1787010
|
[1] |
FUSE
|
R
, Serial Range: -04400304
|
| 4. |
0117080
|
[1] |
HARNESS
|
R
Wiring loom Stromversorgung, Start Serial: 04400490
|
| 4. |
9219820
|
[1] |
HARNESS
|
R
Cable 2700 lg, Serial Range: 04400305-04400489
|
| 4. |
8204750
|
[1] |
HARNESS
|
R
Wire 3700 lang, Serial Range: -04400304
|
| 5. |
2135730
|
[2] |
SOCKET/RECEPTACLE
|
R
Socket A, Start Serial: 04400490
|
| 5. |
7693111
|
[2] |
CONNECTOR, ELEC
|
R
Socket 12/3 a, Serial Range: -04400489
|
| 6. |
2135740
|
[2] |
CONNECTOR, ELEC
|
R
Plug B, Start Serial: 04400490
|
| 6. |
7693121
|
[2] |
CONNECTOR, ELEC
|
R
Plug 12/3 b, Serial Range: -04400489
|
| 7. |
0117061
|
[1] |
HARNESS
|
R
Wire, Start Serial: 04400490
|
| 7. |
8204701
|
[1] |
PIPE
|
BER
Connect.wire, Serial Range: -04400489
|
| 8. |
8255150
|
[1] |
BUZZER
|
R
Blinker
|
| . . |
1787620
|
[2] |
CONNECTOR, ELEC
|
R
Flat plug B6,3-2,5
|
| . . |
2337950
|
[1] |
TERMINAL BOX
|
R
Flat plug housing 6,3 2-polig
|
| 9. |
2154030
|
[17] |
CLAMP
|
R
Pipe clamp
|
| 10. |
0117340
|
[1] |
HARNESS
|
R
Wiring loom, Start Serial: 04400490
|
| 10. |
0106926
|
[1] |
HARNESS
|
R
Wiring loom Quadrant, Serial Range: -04400489
|
| 11. |
2154040
|
[10] |
MOUNTING CLIP
|
R
Pipe clamp
|
| 12. |
6585231
|
[1] |
SOCKET/RECEPTACLE
|
R
Socket
|
| 13. |
6585240
|
[1] |
COVER
|
R
|
