凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (078) - CLEANING FAN (VAR.9049) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
117 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
0117281
|
[1] |
HARNESS
|
R
Adapter cable, Start Serial: 04400405
|
| 1. |
0116860
|
[1] |
HARNESS
|
R
Adapter cable, Serial Range: -04400404
|
| 2. |
2382500
|
[2] |
GROMMET
|
R
Cable ring A24x30x3,5
|
| 3. |
08260451
|
[2] |
VENTILATOR
|
R
Fan, Start Serial: 04400305
|
| 3. |
8305830
|
[1] |
VENTILATOR
|
R
Fan, Serial Range: -04400304
|
| 4. |
614-6025
|
[8] |
BOLT,Hex, M6 x 1 x 25mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86977786
|
| . . |
2379830
|
[8] |
WASHER
|
R
Securing nut Vm 6
|
| . . |
2393860
|
[16] |
WASHER
|
R
Contact washer A 6 Superseded by part number: 86588450
|
| 5. |
8305930
|
[2] |
SUPPORT
|
R
r.h., Start Serial: 04400305
|
| 5. |
8305841
|
[1] |
SUPPORT
|
R
Fan support, Serial Range: -04400304
|
| 6. |
614-8025
|
[8] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43127
|
| . . |
43362
|
[8] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[8] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 7. |
8305920
|
[2] |
SUPPORT
|
R
l.h., Start Serial: 04400305
|
| 8. |
2154030
|
[4] |
CLAMP
|
R
Pipe clamp, Start Serial: 04400405
|
| 9. |
0104114
|
[1] |
POINTER
|
R
Tracer, Start Serial: 04400405 Superseded by part number: 00104115
|
| 10. |
2154040
|
[2] |
MOUNTING CLIP
|
R
Pipe clamp, Start Serial: 04400405
|
| 11. |
1787010
|
[2] |
FUSE
|
R
, Start Serial: 04400405
|
