凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (077) - ELECTRIC TWINE MONITORING (VAR.9208), OPTIONAL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
751 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
2358330
|
[4] |
NUT
|
R
Square nut M 8
|
| 2. |
0103410
|
[4] |
RUBBER INSULATOR
|
R
Isolating sleeve
|
| 3. |
614-8020
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| . . |
43362
|
[4] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[4] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 4. |
8305850
|
[4] |
SUPPORT
|
R
Angle
|
| 5. |
8305860
|
[2] |
SUPPORT
|
R
Contact rail
|
| 6. |
0103400
|
[2] |
WASHER
|
R
Isolating washer
|
| 8. |
614-8025
|
[4] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43127
|
