凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (035) - SUPPORT STAND Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
809 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8161900
|
[1] |
FOOT
|
R
Stand 3000KG
|
| 2. |
238234N0
|
[4] |
NUT
|
FO
Securing nut Vm12 Superseded by part number: 100038
|
| 3. |
2351242
|
[4] |
WASHER
|
R
13
|
| 4. |
8173560
|
[1] |
COVER
|
R
cpl.
|
| 5. |
8173510
|
[1] |
COVER
|
R
|
| 6. |
2123950
|
[1] |
BEARING
|
R
Ta.roller bearing T199
|
| 7. |
838-5850
|
[1] |
LOCK PIN,M8 x 50, Slotted
|
CAS
Tensioning M8 x 50, Slotted Superseded by part number: 412689
|
| 8. |
8173530
|
[1] |
WHEEL GEAR
|
R
Bevel gear
|
| 9. |
8173520
|
[1] |
CONE PINION
|
R
Bevel gear
|
| 10. |
8173540
|
[1] |
ROD
|
R
Spindle 3000 KG
|
| 11. |
838-5840
|
[1] |
LOCK PIN,M8 x 40, Slotted
|
CAS
Tensioning pin 8 x 40 Superseded by part number: 300872
|
| 12. |
2341710
|
[1] |
SHIM
|
R
|
| 13. |
932234R1
|
[1] |
LOCK PIN,M6 x 40, Slotted
|
IH
Superseded by part number: 300869
|
| 14. |
8173500
|
[1] |
LEVER ASSY.
|
R
Hand lever
|
| 15. |
8173480
|
[1] |
TUBE
|
R
Outer tube
|
| 16. |
8173490
|
[1] |
FOOT
|
R
Stand
|
| 17. |
2123940
|
[2] |
NIPPLE, LUBE
|
R
Grease nipple H1 A6
|
| 18. |
8173470
|
[1] |
HOUSING
|
R
|
| 19. |
8173550
|
[1] |
LARGE PIN
|
R
Bolt complete
|
