凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (034) - DRAWBAR HITCH, OPTIONAL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
175 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
2392720
|
[1] |
RING, SNAP
|
R
Snap ring A 50
|
| 2. |
8306550
|
[1] |
SPACER
|
R
Bushing
|
| 3. |
8306560
|
[1] |
SUPPORT
|
R
|
| 4. |
8306580
|
[2] |
SUPPORT
|
R
Strap
|
| 5. |
814-16120
|
[4] |
BOLT,Hex, M16 x 2 x 120mm, Cl 8.8
|
CAS
Hexagonal screw M16x120 Superseded by part number: 321246
|
| . . |
190003871339
|
[4] |
NUT
|
S
Hex, M16 Superseded by part number: 392530
|
| . . |
2393910
|
[4] |
WASHER
|
R
Contact washer A16
|
| 6. |
8306611
|
[1] |
SUPPORT
|
R
Drawbar extension
|
| 7. |
614-16045
|
[6] |
BOLT,Hex, M16 x 2 x 45mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 385922
|
| . . |
2380470
|
[6] |
NUT
|
R
Securing nut Vm16
|
