纽荷兰零件查询(FD20) - CRAWLER DOZER (L1.09[001]) - AUXILIARY ARRANGEMENTS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
599 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4975018. | 4975018 | [2] | PAD | TTFSMALL BLOCK |
| 4976963. | 4976963 | [2] | PLATE | LEC |
| 4979701. | 4979701 | [4] | PAD | LECSMALL BLOCK |
| 4979834. | 4979834 | [2] | CAPPING | LECBEZEL Superseded by part number: 4979701 |
| 8282476. | 8282476 | [4] | SCREW | MOD |
| 10516671. | 10516671 | [4] | LOCK WASHER | BHBLOCKWASHER Superseded by part number: 83990583 |
| 10517071. | 10517071 | [4] | LOCK WASHER,12.2mm ID x 21.1mm OD x 3.1mm Thk | HFILOCKWASHER Superseded by part number: 10517073 |
| 10520021. | 10520021 | [4] | WASHER,12.2mm ID x 22mm OD x 3mm Thk | BHB |
| 10796401. | 10796401 | [2] | COTTER PIN,M3.2 x 18 | TTFSPLIT PIN Superseded by part number: |
| 11112431. | 11112431 | [4] | SCREW,Hex, M12 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 87015736 |
| 79006036. | 79006036 | [2] | BRACKET | LEC |
| 79009171. | 79009171 | [1] | SUPPORT | LEC Superseded by part number: 79029793 |
| 79010146. | 79010146 | [2] | CROSSRAIL | LECCROSS BEAM |
| 79010153. | 79010153 | [2] | TIE-ROD | LECTHREADED TIEROD Superseded by part number: 76003355 |
| 79010787. | 79010787 | [2] | PLATE | LEC |
| 79027865. | 79027865 | [2] | PAD | LECSMALL BLOCK Superseded by part number: 76004440 |
| 79029692. | 79029692 | [2] | TIE-ROD | LECTHREADED TIEROD |
| 79029793. | 79029793 | [1] | SUPPORT | LEC |
| 79029795. | 79029795 | [1] | BRACKET | LEC Superseded by part number: 76007790 |
