凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (037) - BALE CHAMBER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
715 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
2425220
|
[7] |
SCREW
|
R
Countersunk bolt M12x 30
|
| . . |
2361720
|
[7] |
NUT
|
R
Hex, M12 Superseded by part number: 337475
|
| . . |
239389N0
|
[7] |
WASHER
|
FO
Contact washer A12 Superseded by part number: 140046
|
| 2. |
8302361
|
[1] |
BLADE
|
R
Channel knife
|
| 3. |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
Knife carrier
|
| 4. |
R8302281
|
[1] |
SUPPORT
|
R
Angle r.h.
|
| 6. |
8178490
|
[6] |
SCREW
|
R
Flat head bolt M16x 30x 20
|
| . . |
190003871339
|
[6] |
NUT
|
S
Hex, M16 Superseded by part number: 392530
|
| . . |
2393910
|
[6] |
WASHER
|
R
Contact washer A16
|
| 7. |
8302271
|
[1] |
SUPPORT
|
R
Angle l.h.
|
| 8. |
2375770
|
[20] |
SCREW
|
R
Countersunk bolt M10x 25
|
| . . |
100016
|
[20] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| . . |
98-029441
|
[20] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 9. |
614-12025
|
[8] |
BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 300388
|
| 10. |
8305800
|
[1] |
SHIM
|
R
2,0 mm
|
