纽荷兰零件查询(FD20) - CRAWLER DOZER (L3.04[001]) - ROPS CANOPY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
818 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10517671. | 10517671 | [16] | LOCK WASHER,24.3mm ID x 39.8mm OD x 5.5mm Thk | MODLOCKWASHER Superseded by part number: 10572571 |
| 11398031. | 11398031 | [16] | BOLT,Hex, M24 x 2 x 75mm, Cl 10.9 | MKT Superseded by part number: 11398037 |
| 70684837. | 70684837 | [2] | BUSHING,31.72mm ID x 63.75mm OD x 85.85mm L | CMI |
| 79019500. | 79019500 | [4] | LOCKING PLATE | LECLOCKPLATE |
| 79020004. | 79020004 | [2] | SUPPORT | LEC Superseded by part number: 79031578 |
| 79020008. | 79020008 | [2] | SUPPORT | LEC Superseded by part number: 79031579 |
| 79020009. | 79020009 | [4] | SCREW | LEC |
| 79020022. | 79020022 | [1] | FRAME | LECWORK |
| 79027861. | 79027861 | [1] | SHIM | LEC |
| 79032033. | 79032033 | [1] | CANOPY | NHFRAME WORK |
