| 1. |
190003871339
|
[8] |
NUT
|
S
Hex, M16, Start Serial: 04400595 Superseded by part number: 392530
|
| 1. |
2361720
|
[8] |
NUT
|
R
Hex, M12, Serial Range: -04400594 Superseded by part number: 337475
|
| 2. |
2369510
|
[8] |
WASHER
|
R
16,5x 33 x3, Start Serial: 04400595
|
| 2. |
2368440
|
[8] |
WASHER
|
R
13 x 30 x3, Serial Range: -04400594
|
| 3. |
8303941
|
[2] |
PLUG
|
R
Chain M16x 8x52x33gl Superseded by part number: R8303941
|
| 4. |
8303932
|
[2] |
BUSHING
|
R
Chain M16x 8x52x22gl Superseded by part number: R8303932
|
| 5. |
814-12030
|
[8] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
CAS
Hexagonal screw M12x 30 Superseded by part number: 9706687
|
| . . |
239389N0
|
[8] |
WASHER
|
FO
Contact washer A12 Superseded by part number: 140046
|
| 6. |
8309651
|
[1] |
SUPPORT
|
R
- ab Nr., Start Serial: 04400305
|
| 6. |
8303860
|
[1] |
SUPPORT
|
R
r.h. - bis Nr., Serial Range: -04400304
|
| 7. |
238234N0
|
[4] |
NUT
|
FO
Securing nut Vm12 Superseded by part number: 100038
|
| 9. |
8305990
|
[4] |
SHIFTER ROLLER
|
R
Roller
|
| 10. |
614-6020
|
[42] |
BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120100
|
| . . |
825-1406
|
[42] |
NUT,M6, Cl 8
|
CAS
Superseded by part number: 86500688
|
| . . |
2393860
|
[42] |
WASHER
|
R
Contact washer A 6 Superseded by part number: 86588450
|
| 11. |
6496940
|
[14] |
CYLINDER END CAP
|
R
Bearing
|
| 12. |
8179590
|
[14] |
SUPPORT
|
R
|
| 13. |
98-029447
|
[28] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 14. |
931171R1
|
[28] |
BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd
|
IH
Hexagonal screw M 8x 16 Superseded by part number: 16043224
|
| 15. |
8303850
|
[1] |
SUPPORT
|
R
l.h., Serial Range: -04400304
|
| 16. |
2151080
|
[4] |
SCREW
|
R
Flat head bolt M16x 50
|
| 17. |
2380470
|
[4] |
NUT
|
R
Securing nut Vm16
|
| 18. |
8305971
|
[1] |
SHEET
|
R
Cover
|
| 19. |
8305982
|
[1] |
SHEET
|
R
End shutter
|
| 20. |
8306000
|
[3] |
SHIFTER ROLLER
|
R
Roller, Serial Range: -04400434
|
| 21. |
6239350
|
[2] |
SPACER
|
R
tube, Start Serial: 04400305
|
| 23. |
2353941
|
[2] |
SCREW
|
R
Flat head bolt M12x 50, Start Serial: 04400305
|
| 24. |
8311600
|
[2] |
SUPPORT
|
R
Strap, Start Serial: 04400305
|
| 25. |
6704090
|
[2] |
SPACER
|
R
ring, Start Serial: 04400305
|
| 26. |
2355290
|
[1] |
BOLT (SPREADER)
|
R
Hexagonal screw M10x 25, Start Serial: 04400595
|
| 27. |
2393941
|
[1] |
WASHER
|
R
Contact washer B10, Start Serial: 04400595
|
| 28. |
2426650
|
[1] |
WASHER
|
R
15, Start Serial: 04400595
|
| 29. |
8280520
|
[1] |
LARGE PIN
|
R
Pin, Start Serial: 04400595
|
| 30. |
8280540
|
[1] |
SUPPORT
|
R
Plate, Start Serial: 04400595
|
| 31. |
814-8045
|
[1] |
BOLT,Hex, M8 x 1.25 x 45mm, Cl 8.8
|
CAS
, Start Serial: 04400595 Superseded by part number: 16044124
|
| . . |
2381320
|
[1] |
NUT
|
R
Securing nut Vm 8, Start Serial: 04400595 Superseded by part number: 86528579
|
| . . |
2369122
|
[1] |
WASHER
|
R
8,4, Start Serial: 04400595 Superseded by part number: 14496504
|
| 32. |
2379142
|
[1] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin 5x 20-b, Start Serial: 04400595
|
| 33. |
0021550
|
[1] |
SPRING
|
R
Compress.spring, Start Serial: 04400595
|
