| 1. |
8305300
|
[1] |
SHEET
|
R
Front plate r.h.
|
| 2. |
6464920
|
[1] |
CYLINDER ASSY.
|
R
Gas spring
|
| 3. |
614-8025
|
[2] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43127
|
| . . |
43362
|
[2] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[2] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 4. |
2381320
|
[2] |
NUT
|
R
Securing nut VM 8 Superseded by part number: 86528579
|
| 5. |
6543130
|
[2] |
HINGE
|
R
|
| 6. |
614-6016
|
[8] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86508568
|
| . . |
825-1406
|
[8] |
NUT,M6, Cl 8
|
CAS
Superseded by part number: 86500688
|
| . . |
2393860
|
[8] |
WASHER
|
R
Contact washer A 6 Superseded by part number: 86588450
|
| 7. |
8305292
|
[1] |
SHEET
|
R
Front plate l.h.
|
| 8. |
8305532
|
[1] |
SHEET
|
R
Flywheel guard
|
| 9. |
6877470
|
[2] |
STOP
|
R
Rubber pad
|
| 10. |
931171R1
|
[8] |
BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd
|
IH
Hexagonal screw M 8x 16 Superseded by part number: 16043224
|
| . . |
239393N1
|
[8] |
WASHER
|
FO
Contact washer B 8 Superseded by part number: 322358
|
| 11. |
2356472
|
[1] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin, Start Serial: 04400305
|
| 12. |
2368400
|
[1] |
WASHER
|
R
, Start Serial: 04400305
|
| 13. |
5036930
|
[1] |
SPRING
|
R
Compress.spring, Start Serial: 04400305
|
| 14. |
7391621
|
[1] |
SUPPORT
|
R
Locking plate, Start Serial: 04400305
|
| 15. |
7391631
|
[1] |
LARGE PIN
|
R
Shaft, Start Serial: 04400305
|
| 16. |
2158990
|
[1] |
RING, SNAP
|
R
Snap ring A 22, Start Serial: 04400305
|
| 17. |
0085230
|
[1] |
SPACER
|
R
Bushing, Start Serial: 04400305
|
| 18. |
6486200
|
[1] |
LARGE PIN
|
R
Pin, Start Serial: 04400305
|
| 19. |
98-029441
|
[1] |
WASHER
|
FO
Contact washer A10, Start Serial: 04400305 Superseded by part number: 140045
|
| 20. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
, Start Serial: 04400305
|
| 21. |
8262130
|
[1] |
SUPPORT
|
R
, Start Serial: 04400305
|
| 22. |
614-8020
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
, Start Serial: 04400305 Superseded by part number: 120104
|
