纽荷兰零件查询(FD20) - CRAWLER DOZER (L3.11[001]) - APRONS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
772 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10516871. | 10516871 | [5] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 10517271. | 10517271 | [28] | LOCK WASHER,16.2mm ID x 27.7mm OD x 4mm Thk | BHBLOCKWASHER Superseded by part number: 10572173 |
| 10571771. | 10571771 | [4] | LOCK WASHER,M8 | CASLOCKWASHER Superseded by part number: 83990583 |
| 11106231. | 11106231 | [5] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LECBOLT, Hex, M10 x 25, 10.9, Full Thd |
| 11118537. | 11118537 | [28] | SCREW | LEC Superseded by part number: 374835 |
| 12642021. | 12642021 | [4] | WASHER | BHB Superseded by part number: 63707, 86625263 |
| 12646821. | 12646821 | [5] | WASHER,10.2mm ID x 25mm OD x 2mm Thk | BHB Superseded by part number: 12646824 |
| 16043631. | 16043631 | [4] | SCREW,Hex, M8 x 25mm, Cl 10.9, Full Thd | BHBBOLT, Hex, M8 x 25, 10.9 Superseded by part number: 43234 |
| 79005240. | 79005240 | [28] | WASHER,16.8mm ID x 36mm OD x 8mm Thk | LEC |
| 79010568. | 79010568 | [1] | GUARD | LECPROTECTION |
| 79011692. | 79011692 | [1] | COVER | LECPROTECTION |
| 79017100. | 79017100 | [1] | GUARD | LECPROTECTION |
| 79017101. | 79017101 | [1] | GUARD | LECPROTECTION |
| 79017104. | 79017104 | [1] | COVER | LEC |
| 79028463. | 79028463 | [1] | GUARD | LECPROTECTION |
| 79028464. | 79028464 | [1] | GUARD | LECPROTECTION |
| 79029800. | 79029800 | [1] | COVER | LEC |
