纽荷兰零件查询(FD20) - CRAWLER DOZER (L3.11/1[001]) - BOTTOM GUARDS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
702 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 547737. | 547737 | [1] | PLUG | LEC |
| 10516871. | 10516871 | [5] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 10571771. | 10571771 | [4] | LOCK WASHER,M8 | CASLOCKWASHER Superseded by part number: 83990583 |
| 10572371. | 10572371 | [26] | LOCK WASHER,M20 | TTFWASHER, LOCK, M20 Superseded by part number: |
| 11106231. | 11106231 | [5] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LECBOLT, Hex, M10 x 25, 10.9, Full Thd |
| 11124831. | 11124831 | [26] | BOLT,Hex, M20 x 55, 10.9, Full Thd | BASSCREW Superseded by part number: 9843495 |
| 12642021. | 12642021 | [4] | WASHER | BHB Superseded by part number: 63707, 86625263 |
| 12646821. | 12646821 | [5] | WASHER,10.2mm ID x 25mm OD x 2mm Thk | BHB Superseded by part number: 12646824 |
| 16043631. | 16043631 | [4] | SCREW,Hex, M8 x 25mm, Cl 10.9, Full Thd | BHBBOLT, Hex, M8 x 25, 10.9 Superseded by part number: 43234 |
| 79017104. | 79017104 | [1] | COVER | LEC |
| 79029800. | 79029800 | [1] | COVER | LEC |
| 79032222. | 79032222 | [26] | WASHER,21mm ID x 40mm OD x 8mm Thk | LEC |
| 79033519. | 79033519 | [2] | GUARD | LECPROTECTION |
| 79033520. | 79033520 | [1] | GUARD | LECPROTECTION |
| 79033522. | 79033522 | [1] | GUARD | LECPROTECTION |
| 79033523. | 79033523 | [1] | GUARD | LECPROTECTION |
| 79033524. | 79033524 | [1] | GUARD | LECPROTECTION |
