神钢零件查询(F4HFE613F E003) - ENGINE 5801398291 - 84359538 (1/12-) (10.105.02) - CONNECTING ROD (504336352) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
561 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2831298 | [6] | CONNECTING ROD | TORASSY |
| . . | 2831298R | [6] | REMAN-CONNECTING ROD | TORF4HFE613F E003 ENGINE 5801398291 - 84359538 |
| . . | 2831298C | [1] | CORE-ROD CONNECTING | TORReturn Number |
| 2. | 2856309 | [6] | CRANKSHAFT BEARING | BHB |
| 2. | 4892715 | [6] | BEARING LINER | TORBEARING, CON. ROD |
| 3. | 2831297 | [2] | FLANGE BOLT,Hex, M10 x 1.25 x 52mm, Cl 10.9 | TOR |
| 5. | 4895746 | [1] | | |
| 6. | 4892708 | [1] | BUSHING,38.02mm ID x 41.01mm OD x 33.4mm L | TOR |
