神钢零件查询(F4HFE613F E003) - ENGINE 5801398291 - 84359538 (1/12-) (10.106.01) - CAMSHAFT - TIMING CONTROL (504345141) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
710 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899079 | [6] | SCREW,Hex Flg, M8 x 1.25 x 25 | TOR |
| 2. | 4896380 | [1] | DRIVEN GEAR | TOR |
| 3. | 4899068 | [2] | BOLT,Flng, M8 x 1.25 x 16mm | BAS |
| 4. | 4897457 | [1] | SUPPORT | TOR |
| 5. | 84342155 | [1] | CAMSHAFT | BRRAssy Superseded by part number: 504345138 |
| 5. | 504345138R | [1] | REMAN-CAMSHAFT | RACF4HFE613F E003 Engine 5801398291 - 84359538, Assy, Reman for New PN 84342155 |
| 5. | 504345138C | [1] | Return Number | RACReturn Number |
| 6. | 4899080 | [1] | DOWEL,M6 x 8 L | TOR |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CON |
