| 1. |
614-6016
|
[16] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86508568
|
| . . |
825-1406
|
[16] |
NUT,M6, Cl 8
|
CAS
Superseded by part number: 86500688
|
| . . |
2393860
|
[16] |
WASHER
|
R
Contact washer A 6 Superseded by part number: 86588450
|
| 2. |
6543130
|
[4] |
HINGE
|
R
|
| 3. |
8262090
|
[1] |
SHEET
|
R
Side door l.h., Start Serial: 04400305
|
| 3. |
8305450
|
[1] |
SHEET
|
R
Side door l.h., Serial Range: -04400304
|
| 4. |
930269R1
|
[1] |
BOLT,Hex, M8 x 1.25 x 18mm, Cl 8.8, Full Thd
|
IH
Hexagonal screw M 8x 18, Serial Range: -04400304 Superseded by part number: 86625000
|
| 5. |
2381320
|
[1] |
NUT
|
R
Securing nut VM 8, Serial Range: -04400304 Superseded by part number: 86528579
|
| 6. |
8167800
|
[1] |
SUPPORT
|
R
, Serial Range: -04400304
|
| 7. |
0702173
|
[1] |
HANDLE
|
R
Cap
|
| 8. |
8171300
|
[1] |
SUPPORT
|
R
, Serial Range: -04400304
|
| 9. |
6238890
|
[1] |
SPRING
|
R
Tension spring, Serial Range: -04400304
|
| 10. |
6464920
|
[2] |
CYLINDER ASSY.
|
R
Gas spring
|
| 12. |
614-8025
|
[4] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43127
|
| . . |
43362
|
[4] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[4] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 13. |
6877470
|
[2] |
STOP
|
R
Rubber pad
|
| 14. |
6100971
|
[4] |
SCREW
|
R
Flat head bolt M 8x 16
|
| . . |
239393N1
|
[4] |
WASHER
|
FO
Contact washer B 8 Superseded by part number: 322358
|
| 15. |
931171R1
|
[3] |
BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd
|
IH
Hexagonal screw M 8x 16 Superseded by part number: 16043224
|
| 16. |
8305391
|
[1] |
SHEET
|
R
Side panel l.h.
|
| 17. |
614-8020
|
[3] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| 19. |
8214500
|
[3] |
ANGLE
|
R
|
| 20. |
8221243
|
[1] |
SHEET
|
R
Guard plate l.h.
|
| 21. |
8305620
|
[1] |
SHEET
|
R
Side door l.h.
|
| 22. |
8305642
|
[1] |
SUPPORT
|
R
- bei 2,00 M Aufsammler
|
| 22. |
8307230
|
[1] |
SUPPORT
|
R
- bei 2,00 M Aufsammler
|
| 24. |
8307250
|
[1] |
CONNECTING STRIP
|
R
Ledge bei 2,00 M Aufsammler
|
| 25. |
7391631
|
[1] |
LARGE PIN
|
R
Shaft, Start Serial: 04400305
|
| 26. |
7391621
|
[1] |
SUPPORT
|
R
Locking plate, Start Serial: 04400305
|
| 27. |
5036930
|
[1] |
SPRING
|
R
Compress.spring, Start Serial: 04400305
|
| 28. |
2368400
|
[1] |
WASHER
|
R
, Start Serial: 04400305
|
| 29. |
2356472
|
[1] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin, Start Serial: 04400305
|
| 30. |
0085230
|
[1] |
SPACER
|
R
Bushing, Start Serial: 04400305
|
| 31. |
2158990
|
[1] |
RING, SNAP
|
R
Snap ring A 22, Start Serial: 04400305
|
| 32. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
, Start Serial: 04400305
|
| 33. |
98-029441
|
[1] |
WASHER
|
FO
Contact washer A10, Start Serial: 04400305 Superseded by part number: 140045
|
| 34. |
8262060
|
[1] |
SUPPORT
|
R
, Start Serial: 04400305
|
| 35. |
6486200
|
[1] |
LARGE PIN
|
R
Pin, Start Serial: 04400305
|
| 36. |
6367921
|
[2] |
SCREW
|
R
Flat head bolt M 6x 16
|
| . . |
2393920
|
[2] |
WASHER
|
R
Contact washer B 6
|
