凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (052) - R.H. PANELLING, FRONT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
997 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
646492.0
|
[2] |
Gas spring
|
|
| 2. |
238132.0
|
[4] |
Securing nut VM 8
|
|
| 3. |
237442.0
|
[4] |
Hexagonal screw M 8x 25
|
|
| . . |
236170.0
|
[4] |
Hexagonal nut M 8
|
|
| . . |
239387.0
|
[4] |
Contact washer A 8
|
|
| 4. |
687747.0
|
[2] |
Rubber pad
|
|
| 5. |
610097.1
|
[2] |
Flat head bolt M 8x 16
|
|
| . . |
239393.1
|
[2] |
Contact washer B 8
|
|
| 6. |
070217.3
|
[1] |
Cap
|
|
| 7. |
817130.0
|
[1] |
Support - bis Nr. 04400304
|
|
| 8. |
623889.0
|
[1] |
Tension spring - bis Nr. 04400304
|
|
| 9. |
244138.0
|
[1] |
Hexagonal screw M 8x 18, - bis Nr. 04400304
|
|
| 11. |
816780.0
|
[1] |
Support - bis Nr. 04400304
|
|
| 12. |
237465.0
|
[8] |
Hexagonal screw M 6x 16
|
|
| . . |
236169.0
|
[8] |
Hexagonal nut M 6
|
|
| . . |
239386.0
|
[8] |
Contact washer A 6
|
|
| 13. |
654313.0
|
[2] |
Hinge
|
|
| 14. |
826210.0
|
[1] |
Side door r.h. - ab Nr. 04400305
|
|
| . . |
830546.0
|
[1] |
Side door r.h. - bis Nr. 04400304
|
|
| 15. |
237439.0
|
[3] |
Hexagonal screw M 8x 16
|
|
| 16. |
830540.1
|
[1] |
Side panel r.h.
|
|
| 17. |
236200.0
|
[3] |
Hexagonal screw M 8x 20
|
|
| 19. |
821450.0
|
[3] |
Angle
|
|
| 20. |
822125.3
|
[1] |
Guard plate r.h.
|
|
| 21. |
215899.0
|
[1] |
Snap ring A 22, - ab Nr. 04400305
|
|
| 22. |
008523.0
|
[1] |
Bushing - ab Nr. 04400305
|
|
| 23. |
739162.1
|
[1] |
Locking plate - ab Nr. 04400305
|
|
| 24. |
503693.0
|
[1] |
Compress.spring - ab Nr. 04400305
|
|
| 25. |
236840.0
|
[1] |
Washer - ab Nr. 04400305
|
|
| 26. |
235647.1
|
[1] |
Tensioning pin - ab Nr. 04400305
|
|
| 27. |
739163.1
|
[1] |
Shaft - ab Nr. 04400305
|
|
| 28. |
648620.0
|
[1] |
Pin - ab Nr. 04400305
|
|
| 29. |
826206.0
|
[1] |
Support - ab Nr. 04400305
|
|
| 30. |
239388.0
|
[1] |
Contact washer A10, - ab Nr. 04400305
|
|
| 31. |
236171.0
|
[1] |
Hexagonal nut M10, - ab Nr. 04400305
|
|
| 32. |
636792.1
|
[2] |
Flat head bolt M 6x 16
|
|
| . . |
239392.0
|
[2] |
Contact washer B 6
|
|
