凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (053) - R.H. PANELLING, REAR Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
417 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
6100991
|
[2] |
SCREW
|
R
Flat head bolt M 8x 25
|
| . . |
43362
|
[2] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[2] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 2. |
7912090
|
[2] |
MUDFLAP
|
R
Floor covering
|
| 3. |
2365100
|
[6] |
SCREW
|
R
Flat head bolt M10x 20x12
|
| . . |
100016
|
[6] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| . . |
98-029441
|
[6] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 4. |
8170720
|
[1] |
LARGE PLATE
|
R
Strap
|
| 5. |
8305070
|
[1] |
SHEET
|
R
Yarn box
|
| 6. |
6543130
|
[2] |
HINGE
|
R
|
| 7. |
614-6016
|
[8] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86508568
|
| . . |
825-1406
|
[8] |
NUT,M6, Cl 8
|
CAS
Superseded by part number: 86500688
|
| . . |
2393860
|
[8] |
WASHER
|
R
Contact washer A 6 Superseded by part number: 86588450
|
| 8. |
6464920
|
[2] |
CYLINDER ASSY.
|
R
Gas spring
|
| 9. |
2373700
|
[4] |
SCREW
|
R
Hexagonal screw M 8x 30 Superseded by part number: 325-159
|
| 10. |
2381320
|
[4] |
NUT
|
R
Securing nut VM 8 Superseded by part number: 86528579
|
| 11. |
8305240
|
[1] |
SUPPORT
|
R
Tube
|
| 12. |
2335591
|
[2] |
COVER
|
R
Shim drag
|
| 13. |
9008810
|
[2] |
HOOK
|
R
Spring hook
|
| 14. |
9230660
|
[2] |
VALVE SPRING
|
R
Tension spring
|
| 15. |
9008831
|
[2] |
SUPPORT
|
R
|
| 16. |
614-10025
|
[5] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 11106231
|
| 17. |
6100971
|
[4] |
SCREW
|
R
Flat head bolt M 8x 16
|
| 18. |
8305023
|
[1] |
SHEET
|
R
Support r.h.
|
| 20. |
8305181
|
[1] |
SHEET
|
R
Cover plate r.h.
|
| 21. |
6877470
|
[2] |
STOP
|
R
Rubber pad
|
| 23. |
930269R1
|
[1] |
BOLT,Hex, M8 x 1.25 x 18mm, Cl 8.8, Full Thd
|
IH
Hexagonal screw M 8x 18 Superseded by part number: 86625000
|
| 24. |
6238890
|
[1] |
SPRING
|
R
Tension spring
|
| 25. |
8171300
|
[1] |
SUPPORT
|
R
|
| 26. |
0702173
|
[1] |
HANDLE
|
R
Cap
|
| 27. |
8305133
|
[1] |
SHEET
|
R
Cover
|
