凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (055) - PARKING BRAKE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
451 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8161250
|
[1] |
CLEVIS
|
R
Fork head
|
| 2. |
2375190
|
[1] |
NUT
|
R
Hexagonal nut M16x1,5
|
| 3. |
930111R1
|
[3] |
BOLT,Hex, M10 x 1.5 x 45mm, Cl 8.8
|
IH
Hexagonal screw M10x 45 Superseded by part number: 56614
|
| 4. |
9657080
|
[3] |
SPACER
|
R
bush
|
| 5. |
9656930
|
[3] |
SHIFTER ROLLER
|
R
Cable roller
|
| 6. |
2383160
|
[3] |
NUT
|
R
Securing nut Vm10
|
| 7. |
8168940
|
[1] |
CABLE
|
R
Wire rope 5x142x178,5
|
| 8. |
9031560
|
[1] |
GUIDE
|
R
Rip cord guide
|
| 9. |
2345400
|
[3] |
CLAMP
|
R
Cable clamp 6,5
|
| 10. |
2448180
|
[1] |
TERMINAL STRIP
|
R
Thimble A 6
|
| 12. |
614-10025
|
[2] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 11106231
|
| 13. |
9608410
|
[1] |
BRAKE ASSY.
|
R
Standard brake
|
