凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (016) - LAND WHEELS (VAR.7838) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
799 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
2377130
|
[4] |
BEARING ASSY
|
R
Grvd.ball bearing 6005-2RS Superseded by part number: 24905270
|
| 2. |
2343300
|
[2] |
WASHER
|
R
|
| 3. |
239389N0
|
[2] |
WASHER
|
FO
Contact washer A12 Superseded by part number: 140046
|
| 4. |
614-12020
|
[2] |
BOLT,Hex, M12 x 1.75 x 20mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 43151
|
| 5. |
614-12025
|
[2] |
BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 300388
|
| 6. |
2393951
|
[2] |
WASHER
|
R
Contact washer B12
|
| 7. |
2361720
|
[4] |
NUT
|
R
Hex, M12 Superseded by part number: 337475
|
| 8. |
614-12035
|
[4] |
BOLT,Hex, M12 x 1.75 x 35mm, Cl 8.8, Full Thd
|
IH
|
| 9. |
8172230
|
[1] |
ARM
|
R
Supporting arm lh
|
| 9. |
8172240
|
[1] |
ARM
|
R
Supporting arm rh
|
| 10. |
8172281
|
[2] |
SUPPORT
|
R
U-plate
|
| 14. |
09837060
|
[2] |
WHEEL
|
R
Tyre with tube 16x6,50-8 4Pr
|
| . . |
9192650
|
[2] |
TUBE
|
R
16/6,50-8
|
| 15. |
933128R1
|
[4] |
SNAP RING,M25, Ext
|
IH
Circlip 25x1,2 Superseded by part number: 370002
|
| 16. |
2342391
|
[8] |
WASHER
|
R
|
| 17. |
2378510
|
[8] |
WASHER
|
R
Shim 25x 35x0,5 Superseded by part number: 97-020473
|
| 18. |
295109R91
|
[4] |
BALL BEARING
|
IH
Grvd.ball bearing 6205-2RS Superseded by part number: 84188095
|
| 19. |
8172320
|
[2] |
SHAFT
|
R
D 25x193
|
| 20. |
9192641
|
[2] |
RIM
|
R
Wheel rim 5.50 A x 8
|
| 21. |
9191910
|
[2] |
BUSHING
|
R
Spacer bush
|
