纽荷兰零件查询(FD20) - CRAWLER DOZER (B2.04/1[003]) - TRANSMISSION CLUTCHES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
338 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 70642147. | 70642147 | [8] | PLATE | MKTCLUTCH DRIVING PLATE |
| 70672487. | 70672487 | [2] | SLEEVE | CMI |
| 70688802. | 70688802 | [16] | DISC | LECCLUTCH DRIVING PLATE |
| 70695755. | 70695755 | [12] | SPRING | CMI |
| 73109091. | 73109091 | [2] | CUP | CMI |
| 73122543. | 73122543 | [2] | PISTON | CMIPLUNGER |
| 73122544. | 73122544 | [4] | SPACER | CMIBUSH |
| 74254663. | 74254663 | [2] | RING | MKTLOCKRING Superseded by part number: 70926800 |
| 79003389. | 79003389 | [1] | GEAR | LECDRUM Superseded by part number: 79030933 |
| 79003391. | 79003391 | [1] | GEAR | LECDRUM Superseded by part number: 79030935 |
| 79017816. | 79017816 | [2] | STD EXHAUST VALVE | LECVALVE |
| 79017817. | 79017817 | [2] | SLEEVE | LEC Superseded by part number: 70672487 |
| 79017823. | 79017823 | [2] | O-RING | LECLOCKRING Superseded by part number: 73143625 |
| 79019018. | 79019018 | [2] | PISTON | LECPLUNGER Superseded by part number: 73122543 |
| 79019028. | 79019028 | [2] | HUB | LEC |
| 79019030. | 79019030 | [16] | PLATE | LECCLUTCH DRIVING PLATE Superseded by part number: 79035350 |
