纽荷兰零件查询(FD20) - CRAWLER DOZER (B2.04/1A[001]) - TRANSMISSION CLUTCHES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
715 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10333510. | 10333510 | [3] | PIN | MKT |
| 14468381. | 14468381 | [1] | O-RING | LEC |
| 79030929. | 79030929 | [1] | GEAR | LEC |
| 79030950. | 79030950 | [20] | SPRING | LEC Superseded by part number: 79059106 |
| 79030951. | 79030951 | [20] | DISC | LECDISK |
| 79030962. | 79030962 | [1] | RING | LEC |
| 79030964. | 79030964 | [1] | RING | LEC |
| 79030967. | 79030967 | [1] | DISC | LECDISK |
| 79030969. | 79030969 | [1] | RING | LECRETAINING RING |
| 79031021. | 79031021 | [2] | CLUTCH PLATE,150.7mm ID x 228.5mm OD x 3mm Thk | LECDISK |
| 79040410. | 79040410 | [1] | PISTON | LEC |
| 79040447. | 79040447 | [1] | SPRING | LEC Superseded by part number: 79050979 |
| 79040449. | 79040449 | [1] | HYD CONNECTOR | LECDRUM Superseded by part number: 79031687, 79052511, 79052510 |
| 79041978. | 79041978 | [1] | RING | LECRETAINING RING |
| 79045810. | 79045810 | [1] | KIT | LEC-CONSISTING OF |
| 79050702. | 79050702 | [1] | RING | LECRETAINING RING |
| 79050979. | 79050979 | [1] | SPRING | LEC |
| 79051202. | 79051202 | [1] | DRUM | LEC Superseded by part number: 79093760, 79093763, 79093764, 79093762 |
| 79052510. | 79052510 | [1] | RING,88.6mm ID x 98mm OD x 4.5mm Thk | LEC |
| 79052511. | 79052511 | [1] | SPRING | LEC |
| 79059106. | 79059106 | [20] | SPRING | LEC |
| 79071788. | 79071788 | [1] | DRUM | LEC Superseded by part number: 79093762, 79093763, 79093764, 79093760 |
| 79071789. | 79071789 | [3] | NEEDLE ROLLER | LECPIN |
| 79093760. | 79093760 | [1] | DRUM | LEC |
| 79093762. | 79093762 | [1] | DISC,104.2mm ID x 130mm OD x 2mm Thk | LECDISK |
| 79093763. | 79093763 | [1] | RING,124mm ID x 158mm OD x 2mm Thk | LEC |
| 79093764. | 79093764 | [1] | RING | LECLOCKRING |
