凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (025) - RAM RUNNERS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
789 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8170480
|
[4] |
BAR
|
R
Guide rail
|
| 2. |
2363300
|
[40] |
SCREW
|
R
Countersunk bolt M 8x 25
|
| . . |
43362
|
[40] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[40] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 3. |
8170220
|
[2] |
COVER
|
R
|
| 4. |
8170230
|
[2] |
COVER
|
R
|
| 5. |
614-8020
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| 6. |
8170240
|
[2] |
COVER
|
R
|
| 7. |
2393860
|
[2] |
WASHER
|
R
Contact washer A 6 Superseded by part number: 86588450
|
| 8. |
2394370
|
[2] |
SCREW
|
R
Hexagonal screw M 6x 16
|
| 9. |
8306391
|
[1] |
SHIM
|
R
0,5 mm
|
