凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (024) - RAM Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
358 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
525-5111
|
[4] |
NUT,M22 x 1.5, Cl 8
|
IH
Hexagonal nut M22x1,5
|
| 2. |
5012820
|
[4] |
WASHER
|
R
|
| 3. |
2341790
|
[4] |
SHIM
|
R
s
|
| 4. |
08281390
|
[4] |
SHIFTER ROLLER
|
R
Guide roller Sto30zz
|
| 5. |
2331241
|
[4] |
SHIM
|
R
s 30x 42x1
|
| 6. |
8175630
|
[4] |
WASHER
|
R
|
| 7. |
8175552
|
[4] |
SCREW
|
R
Eccentric bolt mit Position 8
|
| 8. |
2392130
|
[4] |
PLUG
|
R
Locking screw M 8x1
|
| 9. |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
Plunger
|
| 10. |
1798380
|
[2] |
NIPPLE, LUBE
|
R
Grease nipple Am 8x1
|
| 11. |
239389N0
|
[4] |
WASHER
|
FO
Contact washer A12 Superseded by part number: 140046
|
| 12. |
814-12030
|
[4] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
CAS
Hexagonal screw M12x 30 Superseded by part number: 9706687
|
| 13. |
8313040
|
[2] |
ROD, CONNECTING
|
R
Connecting rod mit Pos. 10, 14, 16-19
|
| 14. |
9652010
|
[4] |
SPACER
|
R
Bearing bush
|
| 15. |
R8304380
|
[4] |
LARGE PLATE
|
R
Balance plate
|
| 16. |
2333300
|
[2] |
UNION
|
R
Screw-in union Ll4m
|
| 17. |
1789060
|
[4] |
CLAMP
|
R
Hose binder Wsn 9x450
|
| 18. |
8304322
|
[2] |
PIPE
|
R
Hydr. pipe
|
| 19. |
2111840
|
[2] |
FITTING
|
R
Angle union Ll4m
|
| 20. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 21. |
2373840
|
[2] |
SCREW
|
R
Hexagonal screw M10x 25 rs
|
| 22. |
8304310
|
[2] |
PIN
|
R
|
| 23. |
930269R1
|
[4] |
BOLT,Hex, M8 x 1.25 x 18mm, Cl 8.8, Full Thd
|
IH
Hexagonal screw M 8x 18 Superseded by part number: 86625000
|
| . . |
43362
|
[4] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[4] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 24. |
8304370
|
[2] |
LOCK WASHER
|
R
Flat iron
|
| 25. |
2363300
|
[2] |
SCREW
|
R
Countersunk bolt M 8x 25
|
| . . |
2381320
|
[2] |
NUT
|
R
Securing nut Vm 8 Superseded by part number: 86528579
|
| . . |
2369122
|
[2] |
WASHER
|
R
8,4 Superseded by part number: 14496504
|
| 26. |
9107630
|
[2] |
BAR
|
R
Glide bar
|
| 28. |
8304341
|
[3] |
KNIFE
|
R
Piston knife
|
| 29. |
8305901
|
[1] |
SCRAPER
|
R
Stripper l.h.
|
| . . |
8305911
|
[1] |
SCRAPER
|
R
Stripper r.h. Superseded by part number: 08305911
|
| 30. |
2392520
|
[6] |
SCREW
|
R
Hexagonal screw M12x 30 sb
|
| 32. |
8304351
|
[2] |
KNIFE
|
R
Piston knife
|
| 35. |
2369420
|
[4] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1 Superseded by part number: 321204
|
| 36. |
8312350
|
[2] |
SWATHBOARD
|
R
Wooden slat, Start Serial: 04400595
|
| 37. |
98-029441
|
[4] |
WASHER
|
FO
Contact washer A10, Start Serial: 04400595 Superseded by part number: 140045
|
| 38. |
828-10060
|
[4] |
BOLT,Hex, M10 x 1.5 x 60mm, Cl 10.9
|
CAS
, Start Serial: 04400595 Superseded by part number: 86508619
|
