凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (027) - NEEDLE YOKE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
838 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8162640
|
[4] |
ROD
|
R
Pull spacer mit Pos. 9, 20
|
| 2. |
2375240
|
[4] |
NUT
|
R
Hexagonal nut M20x1,5
|
| 3. |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
Threaded rod
|
| 4. |
838-5850
|
[2] |
LOCK PIN,M8 x 50, Slotted
|
CAS
Tensioning M8 x 50, Slotted Superseded by part number: 412689
|
| 5. |
06608768
|
[2] |
SHIM
|
FO
s 35x 45x1
|
| 6. |
0085600
|
[4] |
SPACER
|
R
Bushing
|
| 7. |
732-5032
|
[4] |
COTTER PIN,M5 x 32
|
CAS
Split pin 5 x 28
|
| 8. |
2343440
|
[2] |
WASHER
|
R
|
| . . |
2342360
|
[1] |
WASHER
|
R
|
| 9. |
0085230
|
[8] |
SPACER
|
R
Bushing
|
| 10. |
8311530
|
[2] |
PIN
|
R
, Start Serial: 04400435
|
| 10. |
8166610
|
[2] |
PIN
|
R
, Serial Range: -04400434
|
| 12. |
100016
|
[8] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 13. |
0000170
|
[4] |
SPRING
|
R
Compress.spring
|
| 14. |
8085442
|
[2] |
RETAINER
|
R
Brake plate mit Pos. 19
|
| 15. |
8085472
|
[2] |
RETAINER
|
R
Brake plate mit Pos. 19
|
| 16. |
8085412
|
[2] |
SUPPORT
|
R
|
| 17. |
614-10025
|
[4] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 11106231
|
| . . |
98-029441
|
[4] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 18. |
2379501
|
[16] |
RIVET
|
R
A 4,8x12
|
| 19. |
8085461
|
[4] |
BRAKE LINING
|
R
|
| 20. |
2369420
|
[6] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1 Superseded by part number: 321204
|
| 21. |
8162431
|
[2] |
SHIN
|
R
Flange
|
| 22. |
2364640
|
[4] |
SCREW
|
R
Flat head bolt M10x 70
|
| 23. |
614-12035
|
[4] |
BOLT,Hex, M12 x 1.75 x 35mm, Cl 8.8, Full Thd
|
IH
|
| . . |
2361720
|
[4] |
NUT
|
R
Hex, M12 Superseded by part number: 337475
|
| . . |
239389N0
|
[4] |
WASHER
|
FO
Contact washer A12 Superseded by part number: 140046
|
| 27. |
8260220
|
[2] |
BRAKE DISC
|
R
, Start Serial: 04400305
|
| . . |
2383160
|
[4] |
NUT
|
R
Securing nut Vm10, Start Serial: 04400305
|
