凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (028) - NEEDLES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
655 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
614-10030
|
[8] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Hex, M10 x 30; 8.8 Superseded by part number: 43140
|
| . . |
100016
|
[8] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| . . |
98-029441
|
[8] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 2. |
8303400
|
[1] |
SUPPORT
|
R
tube
|
| 3. |
2368990
|
[4] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin 8 x 20
|
| 4. |
43362
|
[8] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| 5. |
2442230
|
[8] |
SCREW
|
R
Hexagonal screw M 8x 50
|
| 6. |
614-12040
|
[8] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| . . |
2441440
|
[8] |
NUT
|
R
Hexagonal nut M12
|
| . . |
239389N0
|
[16] |
WASHER
|
FO
Contact washer A12 Superseded by part number: 140046
|
| 8. |
932470R1
|
[4] |
LOCK PIN,M6 x 20, Slotted
|
IH
PIN, LOCK, M6 x 20, Slotted Superseded by part number: 47728756
|
| 9. |
8173700
|
[4] |
SHIFTER ROLLER
|
R
Needle roller
|
| 10. |
08303441
|
[4] |
NEEDLE
|
R
mit Pos. 8, 9
|
| 11. |
930269R1
|
[4] |
BOLT,Hex, M8 x 1.25 x 18mm, Cl 8.8, Full Thd
|
IH
Hexagonal screw M 8x 18 Superseded by part number: 86625000
|
| . . |
98-029447
|
[4] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 12. |
614-10040
|
[16] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120112
|
| 13. |
8173721
|
[4] |
SUPPORT
|
R
Angle
|
| 14. |
8173711
|
[4] |
SUPPORT
|
R
Needle holder
|
