凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (031) - KNOTTER PLATE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
240 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
2154410
|
[4] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin 3 x 26
|
| 2. |
2356472
|
[4] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin
|
| 3. |
8166750
|
[4] |
CONTROL LEVER
|
R
Gear lever mit Pos. 4
|
| 4. |
2155040
|
[4] |
JOINT
|
R
Angular joint Bs 13x10
|
| 5. |
43362
|
[12] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| 6. |
8166951
|
[4] |
ROD
|
R
Threaded rod
|
| 7. |
98-029447
|
[8] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 8. |
2449641
|
[4] |
KNUCKLE JOINT
|
R
Angular joint Asl13
|
| 10. |
0000580
|
[4] |
SHORT SHAFT
|
R
Shaft
|
| 11. |
0000560
|
[4] |
BEARING CARRIER
|
R
Bearing
|
| 12. |
2342111
|
[1] |
WASHER
|
R
|
| 13. |
0000201
|
[4] |
WASHER
|
R
|
| 16. |
0000572
|
[4] |
FINGER
|
R
Twine finger ass.
|
| 17. |
614-10030
|
[8] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Hex, M10 x 30; 8.8 Superseded by part number: 43140
|
| . . |
100016
|
[8] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| . . |
98-029441
|
[8] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 18. |
8176410
|
[4] |
SCREW
|
R
Threaded bolt
|
| 20. |
8166531
|
[4] |
GUIDE
|
R
Twine guide
|
| 21. |
932336R1
|
[8] |
LOCK PIN,M5 x 16, Slotted
|
IH
Tensioning pin 5 x 16 Superseded by part number: 14600670
|
| 22. |
8162251
|
[4] |
LARGE PLATE
|
R
Plate
|
| 24. |
614-8025
|
[4] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43127
|
| 25. |
2394420
|
[4] |
SCREW
|
R
Flat head bolt M 8x 12
|
| 26. |
8166745
|
[4] |
LARGE PLATE
|
R
Knot plate
|
| 27. |
2440040
|
[8] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin 14 x 20
|
| 28. |
930051R1
|
[4] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8
|
IH
Hexagonal screw M10x 40 Superseded by part number: 120112
|
| . . |
930111R1
|
[4] |
BOLT,Hex, M10 x 1.5 x 45mm, Cl 8.8
|
IH
Hexagonal screw M10x 45 Superseded by part number: 56614
|
