凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (032) - KNOTTERS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1010 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8264310
|
[4] |
KNOTTER ASSY.
|
R
Knott.machine cpl, Start Serial: 04400595
|
| 2. |
614-10025
|
[16] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 11106231
|
| 3. |
98-029441
|
[16] |
WASHER
|
FO
Contact washer A10 Superseded by part number: 140045
|
| 4. |
2369420
|
[4] |
LUBE NIPPLE,M6 x 1
|
R
Grease nipple As 6x1 Superseded by part number: 321204
|
| 5. |
8166433
|
[4] |
FRAME
|
R
Knot frame mit Pos. 2 - 4, 8, 13
|
| 6. |
8166542
|
[4] |
BLADE
|
R
Knife
|
| 7. |
0000833
|
[4] |
LOCK ASSY
|
R
Clamp.plate supp.
|
| 8. |
8166571
|
[4] |
BOLT
|
R
Stud bolt
|
| 9. |
8264340
|
[4] |
LOCK ASSY
|
R
Thrust piece, Start Serial: 04400595
|
| 9. |
8166522
|
[4] |
LOCK ASSY
|
R
Thrust piece, Serial Range: -04400594
|
| 10. |
7665720
|
[4] |
SPRING
|
R
Compress.spring
|
| 11. |
2369122
|
[4] |
WASHER
|
R
8,4 Superseded by part number: 14496504
|
| 12. |
2381320
|
[4] |
NUT
|
R
Securing nut Vm 8 Superseded by part number: 86528579
|
| 13. |
2369440
|
[8] |
LUBE NIPPLE
|
R
Grease nipple Cs 6x1
|
| 14. |
2369612
|
[4] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin 3x 30-b
|
| 15. |
932817R1
|
[4] |
LOCK PIN,M5 x 32, Slotted
|
IH
Tensioning pin 5 x 32a Superseded by part number: 14601470
|
| 16. |
8166664
|
[4] |
CONE PINION
|
R
Knot pinion large
|
| 17. |
0000803
|
[4] |
WASHER
|
R
Safety glas
|
| 18. |
8166475
|
[4] |
TWINE RETAINER
|
R
Yarn retainer
|
| 19. |
2356010
|
[4] |
NUT
|
R
Hexagonal nut M14
|
| 20. |
0000781
|
[4] |
SPRING
|
R
Compress.spring
|
| 21. |
8166501
|
[4] |
LOCK ASSY
|
R
Clamping plate
|
| 22. |
0000791
|
[4] |
HOOK
|
R
Spring bracket
|
| 23. |
932741R1
|
[4] |
LOCK PIN,M5 x 22, Slotted
|
IH
Tensioning pin 5 x 22a Superseded by part number: 14166070
|
| 24. |
614-8025
|
[4] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43127
|
| 25. |
98-029447
|
[4] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 26. |
2356310
|
[4] |
SPLIT PIN/SAFETY PIN
|
R
Tensioning pin 4 x 16a
|
| 28. |
8166673
|
[4] |
CONE PINION
|
R
Knot pinion small
|
| 29. |
8166490
|
[4] |
CAM
|
R
section
|
| 30. |
8264320
|
[4] |
KNOTTER HOOK
|
R
Knot hook mit Pos. 31 - 33
|
| 31. |
8166561
|
[4] |
KNOTTER JAW
|
R
Knot tongue
|
| 33. |
P35719
|
[4] |
SPLIT PIN/SAFETY PIN
|
P
Tensioning pin 3 x 22a Superseded by part number: A35719
|
| 40. |
8171780
|
[1] |
GAUGE
|
R
Knotter gauge
|
