凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (112) - BALE STACKER, ELECTRIC FLAP MONITOR (VAR.9045) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
765 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
0117420
|
[1] |
HARNESS
|
R
Wiring loom
|
| 2. |
6744390
|
[3] |
SWITCH
|
R
Pull switch
|
| 3. |
0124660
|
[1] |
BUTTON
|
R
Push button
|
| 4. |
7440711
|
[1] |
RELAY
|
R
Relais
|
| 5. |
0117010
|
[1] |
RELAY
|
R
Pulse relay 12v
|
| 6. |
0116692
|
[1] |
RELAY
|
R
Time relay
|
| 7. |
8309640
|
[1] |
SUPPORT
|
R
|
| 8. |
7721720
|
[1] |
HOOK
|
R
|
| 9. |
734-6356
|
[1] |
COTTER PIN,M6.3 x 56
|
CAS
Split pin 6,3x 56 Superseded by part number: 10797901
|
| 10. |
0117000
|
[1] |
HARNESS
|
R
Wiring loom
|
