凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (111) - BALE STACKER, SAFETY GUARDS (VAR.9045) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
733 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8308691
|
[1] |
SHEET
|
R
Support cover lh.
|
| 2. |
8308671
|
[2] |
SHEET
|
R
Plate
|
| 3. |
831113.1
|
[1] |
Bracket
|
|
| 4. |
614-8025
|
[3] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43127
|
| . . |
43362
|
[3] |
NUT,M8 x 1.25, Cl 10
|
BHB
M8, Cl 10
|
| . . |
98-029447
|
[3] |
WASHER
|
FO
Contact washer A 8 Superseded by part number: 322358
|
| 5. |
0108780
|
[1] |
MIRROR
|
R
+ ab Nr. .....216
|
| 5. |
6189830
|
[1] |
MIRROR
|
R
- bis Nr. .....215
|
| . . |
1787380
|
[1] |
MIRROR
|
R
Glass, mirror - fur 010878.0
|
| . . |
6181910
|
[1] |
MIRROR
|
R
Glass, mirror - fur 618983.0
|
| 6. |
8308712
|
[1] |
SUPPORT
|
R
Mirror support
|
| 7. |
8308701
|
[1] |
FLEXIBLE HOSE
|
R
Support cover rh.
|
| 8. |
931171R1
|
[40] |
BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd
|
IH
Hexagonal screw M 8x 16 Superseded by part number: 16043224
|
