纽荷兰零件查询(FD20) - CRAWLER DOZER (B2.38[001]) - TRANSMISSION LOCK-UP DEVICE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
964 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 593775. | 593775 | [1] | SCREW | MKT Superseded by part number: 4968815 |
| 4977072. | 4977072 | [1] | HANDLE GRIP | LECKNOB Superseded by part number: 76006064 |
| 4985332. | 4985332 | [1] | TORSION SPRING | LEC |
| 10516871. | 10516871 | [3] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 10734201. | 10734201 | [2] | COTTER PIN,M2 x 12 | TTFPIN, SPLIT (COTTER), M2 x 12 Superseded by part number: |
| 11106231. | 11106231 | [3] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LECBOLT, Hex, M10 x 25, 10.9, Full Thd |
| 11701721. | 11701721 | [3] | NUT,M10, Cl 10 | LEC Superseded by part number: 17038131 |
| 12638621. | 12638621 | [2] | WASHER,M10 x 18 x 2 | BHB Superseded by part number: 17095014 |
| 12646821. | 12646821 | [3] | WASHER,10.2mm ID x 25mm OD x 2mm Thk | BHB Superseded by part number: 12646824 |
| 14162270. | 14162270 | [1] | LOCK PIN,M3 x 28, Slotted | TTFPIN |
| 79005513. | 79005513 | [1] | LEVER | LEC Superseded by part number: 79025581 |
| 79005521. | 79005521 | [1] | RING | LECRETAINER |
| 79014651. | 79014651 | [1] | SUPPORT | LEC Superseded by part number: 79025588 |
| 79014659. | 79014659 | [1] | LEVER | LEC Superseded by part number: 79025588, 79025585, 79025582 |
| 79014664. | 79014664 | [1] | TIE-ROD | LECROD |
| 79016930. | 79016930 | [1] | HUB | LECLEVER Superseded by part number: 79025582 |
| 79025581. | 79025581 | [1] | LEVER | LEC |
| 79025582. | 79025582 | [1] | LEVER | LEC |
| 79025585. | 79025585 | [1] | LEVER | LEC Superseded by part number: 79028843 |
| 79025588. | 79025588 | [1] | SUPPORT | LEC |
| 79028843. | 79028843 | [1] | LEVER | LEC |
