纽荷兰零件查询(FD20) - CRAWLER DOZER (B2.38/A[001]) - TRANSMISSION LOCK-UP DEVICE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
531 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4977072. | 4977072 | [1] | HANDLE GRIP | LECKNOB Superseded by part number: 76006064 |
| 4985332. | 4985332 | [1] | TORSION SPRING | LEC |
| 10333710. | 10333710 | [1] | PIN,M4 x 20.00mm | MKT |
| 10571871. | 10571871 | [5] | LOCK WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk | LECWASHER, LOCK, M10 Superseded by part number: 10571873 |
| 10733601. | 10733601 | [2] | COTTER PIN,M3.2 x 22 | TTFPIN, SPLIT (COTTER), M3.2 x 22 |
| 12164721. | 12164721 | [2] | NUT,M10 x 1.25, Cl 10 | TTF |
| 12638621. | 12638621 | [2] | WASHER,M10 x 18 x 2 | BHB Superseded by part number: 17095014 |
| 14496621. | 14496621 | [5] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | TTFM10 x 21 x 2 |
| 14601270. | 14601270 | [1] | ROLL PIN,M5 x 28, Slotted | LECPIN |
| 15970731. | 15970731 | [5] | BOLT,Hex, M10 x 1.25 x 25mm, Cl 10.9, Full Thd | LECSCREW |
| 76005300. | 76005300 | [1] | LEVER | LEC |
| 76006064. | 76006064 | [1] | HANDLE GRIP | LECKNOB |
| 79034854. | 79034854 | [1] | LEVER | LEC |
| 79034857. | 79034857 | [1] | SUPPORT | LEC |
| 79034863. | 79034863 | [1] | SPRING | LEC |
| 79034864. | 79034864 | [1] | SUPPORT | LEC |
| 79034869. | 79034869 | [1] | LEVER | LEC Superseded by part number: 76005300 |
| 79034873. | 79034873 | [1] | SUPPORT | LEC |
| 79034877. | 79034877 | [1] | SHAFT | LEC |
| 79034878. | 79034878 | [1] | SPACER | LEC |
| 79034879. | 79034879 | [1] | ROD-TIP | LECROD |
| 79034880. | 79034880 | [2] | ROD-TIP | LECROD |
