| 1. |
670627R91
|
[1] |
DOOR
|
IH
CHEST ASSY, twine door
|
| 2. |
670628R1
|
[3] |
HINGE
|
IH
twine chest door
|
| . . |
NLS
|
[6] |
NO LONGER SERVICED
|
BAS
RIVET, 3/16 x 5/16 small truss-hd solid (PN 135285)
|
| . . |
103320
|
[7] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| . . |
18473R1
|
[5] |
SCREW,Hex, 5/16"-18 X 5/8", G2
|
IH
BOLT, 5/16 x 5/8 C-Z hex-hd mach Superseded by part number: 326-512
|
| . . |
80681
|
[5] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| . . |
9635082
|
[3] |
NUT,5/16" - 18, Gr 5
|
NH
5/16-18 hex.
|
| . . |
Q397
|
[2] |
WASHER
|
IH
11/32 x 3/4 x 16 ga Superseded by part number: 95-81069
|
| . . |
106884
|
[6] |
RIVET
|
IH
3/16 x 1/2 small truss-hd solid
|
| 3. |
669184R1
|
[2] |
CLAMP
|
IH
twine chest door Superseded by part number: 1333780C1
|
| . . |
435141
|
[4] |
SCREW
|
IH
10-24 x 3/8 slt-pan-hd mach Superseded by part number: 159908
|
| . . |
110633
|
[4] |
NUT,#10-24
|
IH
Superseded by part number: 87304
|
| . . |
106497
|
[4] |
LOCK WASHER,#10
|
IH
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 4. |
670619R2
|
[1] |
|
P
SHEET, twine chest rear, 4771M and below
|
| . . |
14986R1
|
[9] |
BOLT, 5/16 x 1/2 sq-nk crg
|
|
| . . |
17412R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 2
|
IH
3/8 x 3/4 hex-hd mach Superseded by part number: 86500692
|
| . . |
102635
|
[1] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[1] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 5. |
670622R2
|
[1] |
|
P
ANGLE, twine chest
|
| 6. |
B32120
|
[2] |
WASHER
|
IH
twine roller spring cup
|
| . . |
18635R1
|
[2] |
BOLT,Short NK, 1/4"-20 x 3", G2
|
IH
1/4 x 3 znd sq-nk crg Superseded by part number: 111-115
|
| . . |
665621R1
|
[2] |
|
P
NUT, 1/4-20 wing
|
| 7. |
76DS
|
[2] |
SPRING
|
IH
twine tension, replaces 323
|
| 8. |
670621R1
|
[1] |
RING
|
IH
slack arm
|
| 9. |
457094R1
|
[1] |
SPRING
|
IH
slack arm
|
| . . |
103418
|
[1] |
SWITCH,1/4" x 1"
|
NNA
Split (Cotter), 1/4" x 1" Superseded by part number: 132-347
|
| 10. |
352133R1
|
[1] |
PLATE
|
IH
twine guide mounting
|
| . . |
436570
|
[2] |
SCREW,Slotted Pan Hd, #10-24 x 1/2"
|
IH
10-24 x 1/2 slt-pan-hd mach
|
| 11. |
670617R1
|
[1] |
SPARE PART
|
IH
GUIDE, twine Superseded by part number: 670617R2
|
| 12. |
662380R1
|
[1] |
GUIDE
|
IH
PLATE, twine tension inside
|
| 13. |
670620R1
|
[1] |
|
P
BOTTOM, twine chest, 4771M and below
|
| 14. |
670623R91
|
[2] |
|
P
END ASSY, twine chest LH, 4771M and below
|
| 15. |
670626R1
|
[1] |
|
P
SHEET, twine chest front, 4771M and below
|
| 16. |
670625R1
|
[2] |
|
P
PARTITION, twine chest, 4771M and below
|
| 17. |
673407R1
|
[1] |
|
P
CHEST ASSY, twine, 4772M and up
|
| 18. |
673760R1
|
[1] |
PLATE
|
IH
twine tension outside
|
