| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
670678R91
|
[1] |
|
P
CHANNEL ASSY, lower tension
|
| 2. |
667830R2
|
[1] |
|
P
CHANNEL, upper tension
|
| 3. |
671126R91
|
[2] |
SUPPORT
|
IH
ASSY, bale tension
|
| . . |
20485R1
|
[2] |
BOLT,Short NK, 7/16"-14 x 3/4", G5. Full Thd
|
IH
7/16 x 3/4 C-Z sq-nk crg
|
| . . |
473213R1
|
[2] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 znd hex. lock Superseded by part number: 280980
|
| 4. |
670680R1
|
[1] |
SPRING
|
IH
tension channel
|
| . . |
15143R1
|
[1] |
BOLT,Sq Nk, 7/16" - 14 x 3"
|
IH
7/16 x 3 sq-nk crg Superseded by part number: 18700R1
|
| . . |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
7/16-14 hex.
|
| . . |
103322
|
[1] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 5. |
670681R91
|
[2] |
SCREW
|
IH
ASSY, tension adjusting
|
| . . |
12258R1
|
[2] |
WASHER
|
IH
21/32 x 1-1/4 x 11 ga Superseded by part number: 25711R1
|
| 6. |
23372S
|
[2] |
SPACER,1/2" Pipe x 2 9/16"
|
IH
1/2 x 2-9/16 std pipe, replaces 670685R1
|
| . . |
15172R1
|
[2] |
BOLT, 3/8 x 3-1/2 sq-nk crg
|
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
