凯斯零件查询(27) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/65-12/68) (C-26[A]) - POWER TAKE-OFF DRIVE SHAFT CLUTCH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
270 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
662270R1
|
[1] |
PLATE
|
IH
clutch pressure
|
| 2. |
670688R91
|
[1] |
DISC
|
IH
ASSY, clutch Superseded by part number: 3100042R21, 670689R1
|
| 2. |
670974R1
|
[2] |
FACING W/RIVETS, clutch
|
|
| . . |
113343
|
[12] |
|
P
RIVET, 3/16 x 1/2 brass ov-hd tubular
|
| 3. |
670687R11
|
[1] |
SPACER
|
IH
ASSY, clutch
|
| 4. |
662269R1
|
[1] |
PLATE
|
IH
clutch back
|
| . . |
18494R1
|
[3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
3/8 x 1 znd hex-hd mach Superseded by part number: 424-616
|
| . . |
180122
|
[3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
IH
3/8-16 x 1 znd hex-hd cap Superseded by part number: 113-207
|
| . . |
120382
|
[3] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 5. |
662241R1
|
[2] |
RATCHET
|
IH
DOG, overrunning clutch Superseded by part number: 3101008R1
|
| . . |
137185
|
[2] |
COTTER PIN,1/8" x 1"
|
IH
PIN, SPLIT (COTTER), 1/8" x 1" Superseded by part number: 80755
|
| 6. |
21263R1
|
[2] |
CLEVIS PIN,1/2" x 1 11/16'"
|
IH
PIN, 1/2 x 1-11/16 C-Z rod end Superseded by part number: 427-8168
|
| 7. |
M1015
|
[7] |
SPRING
|
IH
clutch
|
| . . |
18710R1
|
[7] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 3", Gr 2
|
IH
BOLT, 1/2 x 3 znd sq-nk crg Superseded by part number: 80280818
|
| . . |
474848R1
|
[7] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 znd hex. lock Superseded by part number: 231-4218
|
| . . |
460908R1
|
[7] |
WASHER
|
IH
17/32 x 1-1/2 x 11 ga C-Z Superseded by part number: 86624147
|
| 8. |
667239R1
|
[2] |
DISC
|
IH
SHIM, over-running clutch dog .010 (or as required)
|
| 9. |
673759R1
|
[2] |
ANCHOR
|
IH
CLIP, clutch dog pin
|
