凯斯零件查询(27) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/65-12/68) (C-27) - POWER TAKE-OFF DRIVE SHAFTS, TWO KNUCKLES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
971 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
455347R1
|
[1] |
VALVE SPRING
|
IH
SPRING, lock pin unit Superseded by part number: 237924A1
|
| 3. |
661406R1
|
[1] |
LOCK WASHER,4.83mm ID x 18.542mm OD x 1.65mm Thk
|
IH
X lock
|
| 4. |
455346R21
|
[1] |
PIN
|
IH
lock unit Superseded by part number: 237924A1
|
| 6. |
568100R92
|
[1] |
YOKE
|
IH
W/QA PIN Superseded by part number: 568100R93
|
| 7. |
576420R1
|
[8] |
RING
|
IH
brg retainer snap
|
| 8. |
569044R91
|
[8] |
BEARING ASSY
|
IH
ASSY, cross Superseded by part number: 84355319
|
| 10. |
80711
|
[2] |
LUBE NIPPLE,65 Degree, 1/8" NPT x 7/8" lg
|
NH
FITTING, 1/8-27 65 deg lub
|
| 11. |
569047R91
|
[2] |
REPAIR KIT
|
IH
KIT, cross service Superseded by part number: 200464C91
|
| 12. |
667816R91
|
[1] |
YOKE
|
IH
& SHAFT ASSY, rectangular
|
| 13. |
613436R1
|
[2] |
CLAMP
|
IH
RING, snap Superseded by part number: 56760
|
| 14. |
613437R1
|
[2] |
THRUST WASHER,62.2mm ID x 71.12mm OD x 1.7mm Thk
|
IH
thrust
|
| 15. |
464920R1
|
[2] |
NYLON BEARING,2.08" ID x 2.8" OD x 0.38"
|
IH
nylon, replaces 613439R1 Superseded by part number: 47941, 579113
|
| 16. |
668405R91
|
[1] |
SHIELD
|
IH
outer
|
| 17. |
670708R1
|
[1] |
|
P
SHIELD ASSY, inner
|
| 19. |
19688R1
|
[1] |
LUBE NIPPLE,1/4"-28 x .44" lg
|
IH
FITTING, 1/4-28 str lub Superseded by part number: 88775
|
| 20. |
667817R91
|
[1] |
YOKE
|
IH
ASSY, tube & sleeve
|
| 21. |
670707R11
|
[1] |
|
P
YOKE ASSY, flange
|
| 22. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4-28 self-tap. lub
|
| 23. |
670706R91
|
[1] |
|
P
SHAFT ASSY, main rear drive
|
| 24. |
668370R91
|
[1] |
JOINT
|
IH
SHAFT ASSY, tractor half drive Superseded by part number: 668370R92
|
